Page 22 - Waterjet

MAXIEM 2040

MACHINE 18'0" x 12'2"
FOOTPRINT: (5,486 mm x 3,696 mm)

X-Y 13'10" x 6'7"
CUTTING TRAVEL: (4,216 mm x 2,019 mm)
±0.002"
REPEATABILITY: MAXIEM 2030
±(0.051 mm)
MACHINE 14'1" x 12'2"
FOOTPRINT: (4,293 mm x 3,696 mm)
X-Y 10'0" x 6'7"
CUTTING TRAVEL: (3,061 mm x 2,019 mm)

REPEATABILITY: ±0.002"
±(0.051 mm)

MAXIEM 1530

MACHINE 14’1” x 10’10”
FOOTPRINT: (4,293 mm x 3,302 mm)
X-Y 10’0” x 5’2”
CUTTING TRAVEL: (3,061 mm x 1,575 mm)
±0.002"
REPEATABILITY:
±(0.051 mm)
MAXIEM 1515
MACHINE 9'3" x 10'10"
FOOTPRINT: (2,819 mm x 3,302 mm)

X-Y 5'2" x 5'2"
CUTTING TRAVEL: (1,575 mm x 1,575 mm) MAXIEM 0707
±0.002" MACHINE 6'7" x 8'3"
REPEATABILITY:
±(0.051 mm) FOOTPRINT: (2,007 mm x 2,515 mm)
X-Y 2'7" x 2'6"
CUTTING TRAVEL: (794 mm x 775 mm)
Specifications subject to change without notice. REPEATABILITY: ±0.002"
600121B © OMAX Corporation April 2014 ±(0.051 mm)
