Fizik Tingkatan 5 Bab 1
18. Jawab soalan di bawah dengan betul. SP 1.4.4 TP3 KBAT Mengaplikasi
Answer the questions below correctly.v

(a) Apabila suatu beban berjisim 0.4 kg digantung kepada hujung suatu spring, pemanjangan spring,
x ialah 6 cm. Panjang spring, l ialah 10 cm. Rajah di bawah menunjukkan beberapa susunan spring
yang dibina daripada beberapa spring yang serupa. Dalam setiap susunan spring, tunjukkan jumlah
panjang sistem spring itu.
When a mass of 0.4 kg is hung on the end of a spring, extension of the spring is 6 cm. The length of the spring is l = 10 cm. The
diagram below shows several spring arrangements constructed from several similar springs. In each spring arrangement, show
the total length of the spring system.
(i) Pemanjangan sistem spring
Extension of system of springs
= 2 × 6 = 12 cm
Jumlah panjang sistem spring
Total length of the spring system
= 10 + 10 + 12 = 32 cm

x cm
0.4 kg

x cm
0.4 kg
(ii) Penerbitan Pelangi Sdn Bhd. All Rights Reserved 6
Pemanjangan sistem spring = = 3 cm
Extension of system of springs 2
Jumlah panjang sistem spring = 10 + 3 = 13 cm
Total length of the spring system

x cm
2
0.4 kg

0.4 kg

(iii) 6
Pemanjangan sistem spring = 6 + = 9 cm
Extension of system of springs 2
Jumlah panjang sistem spring
Total length of the spring system
= 10 + 10 + 9 = 29 cm

0.4 kg
