FASTENERS





                                                                                             17118HP
               high tensile strength    17201HP                      ls head bolt kits
               head bolt kits                                        Our Engine Works performance cylinder head
                                                                     bolts are designed for use with your GM heads.
                 PART NO.  DESCRIPTION                               Everything is included to properly complete your
                                                                     cylinder head installation.  Services 2 heads.
                  17203  SB Chevy,  170,000 PSI
                  17200  SB Chevy,  190,000 PSI                       PART NO.  DESCRIPTION
                  17202  BB Chevy,  170,000 PSI
                 17202HP  BB Chevy,  190,000 PSI                              Pre 2004  -  Kit has (16) M11 x 2.0 that are 155mm long,
                                                                       17118HP  (4) M11 x 2.0 bolts that are 100mm long, & (10) M8 x 1.25” bolts
                  17201  SB Ford,  170,000 PSI                                that are 45mm long  -  TTY  -  GM# 12498545
                 17201HP  SB Ford 302,  190,000 PSI                    800568  2004 & Up  -  Kit has (10) 45mm / 1.770” bolts & (20) 100mm / 3.930” bolts
                                                                              -  TTY  -  GM# 17800568
                 17120HP  Chrysler HEMI 5.7L,  190,000 PSI             800569  2013 & Up  -  LT1 Gen V  -  TTY  -  GM# 11546959





               stainless steel engine fastener kits
               Each kit includes intake manifold, oil pan, valve covers, headers, timing cover, water pump,   17500  17524
               water neck, fuel pump, and distributor hold down in 85,000 KFI tensile strength stainless
               fasteners.  All Hex except 17502.
                 PART NO.  DESCRIPTION
                  17500  SB Chevy
                  17501  SB Chevy, with header bolts
                  17502  Chevy tuned port, socket head
                  17510  BB Chevy
                  17511  BB Chevy, with header bolts
                  17520  SB Ford
                  17521  SB Ford, with header bolts
                  17522  Ford 351 Cleveland
                  17524  Ford 429-460
                  17526  Ford FE 352-390, 428
                  17540  BB Chrysler 440
                  17530  Pontiac 326-455
                  17532  Oldsmobile



                                     469001                        469901
               ls top end &                                                                  BOTTOM END KIT INCLUDES:
               bottom end kits                                                               •   (10) Main Cap Bolts
                                                                                             •   (1) Coolant Plug, Large
               TOP END KIT INCLUDES:                                                         •   (10) Side Main Cap Bolts
               •   (4) Cam Retainer Bolts                                                    •   (3) Cam Bolts
               •   (1) Barbell Oil Plug                                                      •   (12) Rear Cover Bolts
               •   (20) Medium Head Bolts                                                    •   (10) Main Cap Bolts
               •   (3) Cam Bolts                                                             •   (1) Front Oil Galley Press-In Plug
               •   (10) Front Cover Bolts                                                    •   (3) Coolant / Oil Plugs
               •   (4) Oil Pump Bolts                                                        •   (13) Oil Pan Bolts
               •   (10) Short Head Bolts                                                     •   (8) Front Cover Bolts
               •   (4) Lifter Guide Bolts                                                    •   (4) Oil Pump Bolts
               •   (1) Harmonic Balancer Bolt                                                •   (2) Bellhousing Dowels
               •   (1) Camshaft Thrust Plate                                                 •   (2) Oil Pan to Rear Cover Bolts
               •   (4) Coolant Pipe Seal                                                     •   (2) Coolant Air Bleed Bolts

                 PART NO.  DESCRIPTION                                PART NO.  DESCRIPTION
                 469001  LS Top End Kit                                469901  LS Bottom End Kit


      48
