Page 243 - 2018 Master Catalog

STEEL AN ADAPTERS
TEE PIPE ON-THE-SIDE - 825
STEEL AN ADAPTERS PART NO. DESCRIPTION
UNION - 815
582503 -3 Tee, 1/8 MPT
PART NO. DESCRIPTION 582504 -4 Tee, 1/8 MPT

581503 -3
581504 -4 STEEL AN ADAPTERS
581506 -6
TEE PIPE ON-THE-RUN - 826
PART NO. DESCRIPTION
STEEL AN ADAPTERS
STRAIGHT - 816 582603 -3 Tee, 1/8 MPT
582604 -4 Tee, 1/8 MPT
PART NO. DESCRIPTION

581603 -3 X 1/8 MPT STEEL AN ADAPTERS
581604 -4 X 1/8 MPT
581605 -6 X 1/4 MPT STRAIGHT BULKHEAD - 832
PART NO. DESCRIPTION

STEEL AN ADAPTERS 583203 -3
45° ADAPTERS - 823
PART NO. DESCRIPTION STEEL AN ADAPTERS
45° BULKHEAD - 837
582303 -3 X 1/8 MPT
582304 -4 X 1/8 MPT PART NO. DESCRIPTION

583703 -3
583704 -4
STEEL AN ADAPTERS
90° ADAPTERS - 822 STEEL AN ADAPTERS

PART NO. DESCRIPTION 90° BULKHEAD - 833
PART NO. DESCRIPTION
582203 -3 X 1/8 MPT
582204 -4 X 1/8 MPT
583303 -3
583304 -4
583306 -6
STEEL AN ADAPTERS
TUBE SLEEVE & NUTS STEEL AN ADAPTERS
BULKHEAD TEE ON-THE-RUN
PART NO. DESCRIPTION
PART NO. DESCRIPTION
581903 -3AN Tube Sleeve - Steel
581904 -4AN Tube Sleeve - Steel 580403 -3
581803 -3AN Tube Nut - Steel 580404 -4
581804 -4AN Tube Nut - Steel

STEEL AN ADAPTERS STEEL AN ADAPTERS
TEE - 824 BULKHEAD TEE ON-THE-SIDE

PART NO. DESCRIPTION PART NO. DESCRIPTION
582403 -3 583403 -3
582404 -4 583404 -4
582406 -6 592403 Bulkhead Nuts - 3AN
592404 Bulkhead Nuts - 4AN
243
