LEGEND:
INLET
SIGN
CO
CLEAN OUT
MB
MAIL BOX
UTILB
UTILITY BOX
ADA ADA PAD
LIGHT POLE
FIRE HYDRANT
WV
WATER VALVE
GV
GAS VALVE
SANITARY SEWER MANHOLE
STONE/GRAVEL
CONCRETE PAVING
BRICK PAVERS
EDGE OF BITUMINOUS
CONCRETE PAVING
GAS LINE MARKOUT
TELEPHONE MARKOUT
FENCE LINE
WALL

NOTES:
1. THIS SURVEY DOES NOT PURPORT TO IDENTIFY, IF ANY, ENCROACHMENTS,
WETLANDS, UTILITIES, SERVICE LINES OR STRUCTURES BELOW GROUND; DESCRIPTION:
2. PROPERTY SUBJECT TO DOCUMENTS OF RECORD; BEING KNOWN AS LOT 22, AS SHOWN ON A MAP ENTITLED: "SUBDIVISION OF
3. NO ATTEMPT WAS MADE TO DETERMINE IF ANY PORTION OF THIS PROPERTY IS SPRING KNOLLS NORTHWEST,LOCATE IN THE VILLAGE OF NEW SQUARE, TOWN
CLAIMED BY THE STATE OF N.Y. AS TIDELANDS; OF RAMAPO, ROCKLAND COUNTY, NEW YORK", FILED ON AUGUST 20, 1993 IN
4. NO RESPONSIBILITY OR LIABILITY IS ASSUMED BY THE LAND SURVEYOR FOR ANY
OTHER PURPOSE INCLUDING, BUT NOT LIMITED TO USE OF SURVEY FOR SURVEY THE ROCKLAND COUNTY CLERK'S OFFICE AS MAP NO. 6760 IN BOOK 114 OF
AFFIDAVIT, RESALE OF PROPERTY, OR TO ANY OTHER PERSON NOT LISTED IN THE MAPS, PAGE 92.
CERTIFICATION EITHER DIRECTLY OR INDIRECTLY.
5. ONLY COPIES FROM THE ORIGINAL SURVEY MARKED WITH AN ORIGINAL PROFESSIONAL
LAND SURVEYORS EMBOSSED SEAL SHALL BE CONSIDERED VALID COPIES; ALSO KNOWN AS SECTION 42.19, BLOCK 1, LOT 34 AS SHOWN ON THE OFFICIAL
6. SIGNATURE AND EMBOSSED SEAL SIGNIFY THAT THIS SURVEY WAS PREPARED IN TAX MAPS FOR THE VILLAGE OF NEW SQUARE, ROCKLAND COUNTY, NEW YORK.
ACCORDANCE WITH THE EXISTING CODE OF PRACTICE ADOPTED BY THE NEW YORK
STATE BOARD OF PROFESSIONAL ENGINEERS AND LAND SURVEYORS; CERTIFIED TO:
7. UNAUTHORIZED ALTERATION OR ADDITION TO A SURVEY MAP BEARING A
LICENSED PROFESSIONAL LAND SURVEYOR'S SEAL IS A VIOLATION OF SECTION 7209, MEY ASSOCIATES, LLC.
SUBDIVISION 2 OF THE NEW YORK STATE EDUCATION LAW;
8. OFFSETS SHOWN HEREON ARE NOT TO BE USED AS A BASIS FOR ANY CONSTRUCTION
OF PERMANENT STRUCTURES i.e. BUILDINGS, SHEDS, FENCES, ETC.;
9. HORIZONTAL DATUM BASED ON NAD83. VERTICAL DATUM BASED ON NAVD88.

OUTBOUND & TOPOGRAPHIC SURVEY
PREPARED FOR
141 CLINTON LANE
JOHN W. McCORD, Sr.
~ SECTION 42.19 ~
~ BLOCK 1 ~ LOT 34 ~
Headquarters | 640 Herman Road |Unit 1 | Jackson, NJ 08527
New York Office | 225 Dolson Avenue | Suite 201 | Middletown, NY 10940 SITUATED IN THE
Florida Office | 241 Ruby Avenue |Unit 205 | Kissimmee, FL 34741
_____________732-905-5463_________________
www.clearpointservices.com VILLAGE OF NEW SQUARE,
ROCKLAND COUNTY, NEW YORK
CERTIFICATE OF AUTHORIZATION No. 0019218
JOB NO. 22-34605 DATE: 08-01-2022 SCALE 1"=20' STARS NO. 22-34605 SHEET 1 OF 2 PM - ZL
