FORMING FORMING Z8/ZA/ZC SERIES
TAPS Z4/Z5/Z6/Z7 SERIES TAPS Z9/ZB/ZD SERIES

FORMING TAPS WITH OIL GROOVE PLUG & BOTTOMING STYLE FORMING TAPS WITH OIL GROOVE PLUG & BOTTOMING STYLE

Thread Depth / 3.0×D Thread Depth / 3.0×D
Hole Type Hole Type
USCTI USCTI

M
GV HSSE-V3 UNC USCTI 4P~5P 1.5P~2P Bright TiN GV HSSE-V3 MF USCTI 4P~5P 1.5P~2P Bright TiN TiCN
302A
UNF
302A
Bottoming
Plug
Plug
Bottoming
Thread Per Inch EDP No. EDP No.
SIZE Limit No. of Lobe Plug Bottoming SIZE Pitch Limit No. of Lobe Plug Bottoming
UNC UNF
Bright TiN Bright TiN Bright TiN TiCN Bright TiN TiCN
5/16 — 24 H5 4 Z4465 Z5465 Z6465 Z7465 M2 0.4 D3 4 — — — Z9133 ZB133 ZD133
5/16 — 24 H7 4 Z4467 Z5467 Z6467 Z7467 M3 0.5 D5 4 Z8205 ZA205 ZC205 Z9205 ZB205 ZD205
3/8 16 — H5 4 Z4485 Z5485 Z6485 Z7485 M4 0.7 D6 4 Z8246 ZA246 ZC246 Z9246 ZB246 ZD246
3/8 16 — H7 4 Z4487 Z5487 Z6487 Z7487 M5 0.8 D7 4 Z8287 ZA287 ZC287 Z9287 ZB287 ZD287
3/8 — 24 H5 4 Z4505 Z5505 Z6505 Z7505 M6 1.0 D8 4 Z8318 ZA318 ZC318 Z9318 ZB318 ZD318
3/8 — 24 H7 4 Z4507 Z5507 Z6507 Z7507 M8 1.25 D9 4 Z8369 ZA369 ZC369 Z9369 ZB369 ZD369
7/16 14 — H8 4 Z4528 Z5528 Z6528 Z7528 M10 1.5 D10 4 Z8420 ZA420 ZC420 Z9420 ZB420 ZD420
7/16 — 20 H8 4 Z4548 Z5548 Z6548 Z7548 M12 1.75 D11 4 Z850A ZA50A ZC50A Z950A ZB50A ZD50A
1/2 13 — H8 4 Z4568 Z5568 Z6568 Z7568
1/2 13 — H5 4 Z4565 Z5565 Z6565 Z7565 ▶Refer to technical data on page 520~554.
1/2 — 20 H5 4 Z4585 Z5585 Z6585 Z7585 ▶Hardslck coating is available on your request (Bright Finish EDP No + H)
1/2 — 20 H8 4 Z4588 Z5588 Z6588 Z7588
9/16 12 — H7 4 Z4607 Z5607 Z6607 Z7607
9/16 12 — H10 4 Z4600 Z5600 Z6600 Z7600
9/16 — 18 H8 4 Z4628 Z5628 Z6628 Z7628
9/16 — 18 H10 4 Z4620 Z5620 Z6620 Z7620
5/8 11 — H8 4 Z4648 Z5648 Z6648 Z7648
5/8 11 — H10 4 Z4640 Z5640 Z6640 Z7640
5/8 — 18 H10 4 Z4660 Z5660 Z6660 Z7660
3/4 10 — H10 4 Z4700 Z5700 Z6700 Z7700
3/4 10 — H12 4 Z470B Z570B Z670B Z770B
3/4 — 16 H8 4 Z4728 Z5728 Z6728 Z7728
3/4 — 16 H10 4 Z4720 Z5720 Z6720 Z7720
▶Refer to technical data on page 520~554.
▶Hardslck coating is available on your request (Bright Finish EDP No + H)
