SELECTION GUIDE i-Xmill END MILLS

◎ : Excellent ◯ : Good
P M K N
Carbon Steels Alloy Steels Tool Steels Hardened Stainless Cast lron Aluminum
ITEM MODEL DESCRIPTION PAGE Steels Steels Graphite
~HRc35 HRc35~ ~HRc35 HRc35~ ~HRc35 HRc35~ HRc50~ ~HRc28 ~HRc35 ~HRc8
INCH

XB1A i-Xmill BALL INSERT FOR GENERAL PURPOSE ◎ ○ ◎ ○ ◎ ○ ○ ○ ○

XB2C i-Xmill BALL INSERT FOR HARDENED STEEL 598 ○ ◎ ○ ◎ ○ ◎ ◎ ◎

XB1D i-Xmill BALL INSERT FOR GRAPHITE ○ ○ ○ ○ ◎

ZBT / ZBS i-Xmill BALL HOLDERS - STEEL 599

ZBC i-Xmill BALL HOLDERS - CARBIDE 600

XR1A i-Xmill CORNER RADIUS INSERTS FOR GENERAL PURPOSE ◎ ○ ◎ ○ ◎ ○ ○ ○ ○

XR2A i-Xmill CORNER RADIUS INSERTS FOR HARDENED STEEL 601 ○ ◎ ○ ◎ ○ ◎ ◎ ◎

XR1D i-Xmill CORNER RADIUS INSERTS FOR GRAPHITE ○ ○ ○ ○ ◎

ZRT / ZRS i-Xmill CORNER RADIUS HOLDERS - STEEL 602

METRIC

XB1N i-Xmill BALL INSERT FOR GENERAL PURPOSE ◎ ○ ◎ ○ ◎ ○ ○ ○ ○

XB2N i-Xmill BALL INSERT FOR HARDENED STEEL 603 ○ ◎ ○ ◎ ○ ◎ ◎ ◎

XBAD i-Xmill BALL INSERT FOR GRAPHITE ○ ○ ○ ○ ◎

ZBT / ZBS i-Xmill BALL HOLDERS - STEEL 604

ZBC i-Xmill BALL HOLDERS - CARBIDE 605

XRAA i-Xmill CORNER RADIUS INSERTS FOR GENERAL PURPOSE ◎ ○ ◎ ○ ◎ ○ ○ ○ ○

XRBA i-Xmill CORNER RADIUS INSERTS FOR HARDENED STEEL 606 ○ ◎ ○ ◎ ○ ◎ ◎ ◎

XRAD i-Xmill CORNER RADIUS INSERTS FOR GRAPHITE ○ ○ ○ ○ ◎

ZRT / ZRS i-Xmill CORNER RADIUS HOLDERS - STEEL 608

ASSEMBLY RECOMMENDATIONS 609

RECOMMENDED CUTTING CONDITIONS 610
