STEP BLOCKS & CLAMPS

11L17 STEEL, CARBURIZED-HARDENED, BLACK OXIDE FINISH

Step Block
& Clamp
Set

An assortment of Step Clamps and
Step Blocks in a handy wooden
holder. Available for stud sizes from
3/8-16 to 3/4-10 (M10 to M20 metric
studs).
STEP BLOCK & CLAMP SETS

STUD STEP CLAMPS STEP BLOCK PAIRS
PART NO. SIZE (2) EACH (2) EACH HOLDER
CL-10-SBC 3/8-16 or M10 CL-32-STC, CL-34-STC, CL-36-STC STANDARD CL-10-BS, CL-20-BS, CL-30-BS CL-1-BSH
CL-20-SBC 1/2-13 or M12 CL-42-STC, CL-44-STC, CL-46-STC STANDARD CL-10-BS, CL-20-BS, CL-30-BS CL-1-BSH
CL-40-SBC HIGH-RISE CL-40-BS, CL-50-BS, CL-60-BS CL-2-BSH
CL-30-SBC 5/8-11 or M16 CL-52-STC, CL-54-STC, CL-56-STC STANDARD CL-10-BS, CL-20-BS, CL-30-BS CL-1-BSH
CL-50-SBC HIGH-RISE CL-40-BS, CL-50-BS, CL-60-BS CL-2-BSH
CL-60-SBC 3/4-10 or M20 CL-64-STC, CL-66-STC, CL-68-STC HIGH-RISE CL-40-BS, CL-50-BS, CL-60-BS CL-3-BSH

7
Why Carr Lane Roemheld

Swing Clamps?

Designed for 1,000,000 cycles

2,000,000+ cycles tested at full load
• Rod diameter 30% larger to eliminate part deflection

• Viton wiper is standard (metal wiper optional)
• Exclusive safety clutch design available to prevent damage to part, fixture, or
operator
• Reinforced swivel mechanism with 2 or 3 helix paths depending on size for longer life
• Up to 7500 psi maximum pressure for more compact clamp design

• Position monitoring available, either inductive or pneumatic via movable sensing bolt
• Over 1000 different standard sizes and styles available with clamping forces from
130 lb. to 8265 lb. stroke up to 2”
• Special stroke and clamping forces available upon request.

See Page 640-650
