Especificaciones Ópticas

4000 K 5000 K

1.98 SDCM F5000K
0.8 Max=9629 [1.0=20000] 0.72 SDCM F4000K 0.8 Max=6023 [1.0=20000]
0.7 0.7
0.6 0.6
Distribución Spectrum 0.5 x=0.3788 y=0.3799 Spectrum 0.5 x=0.3495 y=0.3641
0.4
0.4
espectral 0.3 0.3
0.2 0.2
0.1 0.1
0.0 0.0
380 500 600 700 800 380 500 600 700 800
Wavelength(nm) Wavelength(nm)
-/+180 -/+180
-120 120 -120 120

-90 0 90 -90 0 90
1200 1100
Diagrama de 2400 2200
intensidad polar
3600 3300
4800 4400
6000 5500
-30 30 -30 30
0 0
UNIT: cd UNIT: cd
AVERAGE BEAM ANGLE(50%): 42.0 DEG AVERAGE BEAM ANGLE(50%): 41.6 DEG
Planar Illuminance Curve Planar Illuminance Curve
E(LX) MH=10m E(LX) MH=10m
55.0 C0/180 55.0 C0/180
C90/270 C90/270
49.5 49.5
44.0 44.0
38.5 38.5
Diagrama cartesiano 33.0 33.0
de intensidad 27.5 27.5
22.0 22.0
16.5 16.5
11.0 11.0
5.5 5.5
0 0
-25- 20 -15- 10 -5 05 10 15 20 25 -25- 20 -15- 10 -5 05 10 15 20 25
Distance(m) Distance(m)
Flux out: 1506 lm Flux out: 1500 lm

Diagrama de haz

Height Eavg, Emax Angle: 41.15deg Diameter Height Eavg, Emax Angle: 41.32deg Diameter
Note: The Curves indicate the illuminated area and the average Note: The Curves indicate the illuminated area and the average
illumination when the Luminaire is at different distance. illumination when the Luminaire is at different distance.
