PUMPS AND COUNTER CURRENT SWIMMING
SERIE
NEW MINIPUMP
SERIE
SELF-PRIMING PUMP
BOMBA AUTOASPIRANTE
Bush connections included with the pump.
Manguitos incluidos con la bomba.
A
G
D
PALLET: 35 u.
120 × 80 × 175 cm
D BOX: 1 u.
F 49 × 21 × 32 cm 175
C
E
32
21
80
B 120
H 49
I
POWER DIMENSIONS WEIGHT VOLUME
CODE
kW CV A B C D E F G H I kg m3
NEWMP025M 0,20 1/4 438 292 260 Ø50 180 274 208 168 199 8,0 0,033
NEWMP033M 0,25 1/3 438 292 260 Ø50 180 274 208 168 199 8,0 0,033
NEWMP050M 0,37 1/2 438 292 260 Ø50 180 274 208 168 199 8,8 0,033
NEWMP075M 0,55 3/4 438 292 260 Ø50 180 274 208 168 199 8,8 0,033
