Tool kits

CZD-40 HSS M3÷M20 INDEX Z1-040011-0000

Screw pitch
Taps Screwing dies gauge Taps wrench Die stock Screwdriver

DIN-352 HSS dla M3÷M12 PBPc RWWe
DIN-352/2 HSS dla M14÷M20 DIN-EN 22 568 HSS 800 MWGa PBGa

CONTENTS

Ć25 x 9:M3 | M4 | M5 | Nr 2 zm.:
M3 | M4 | M5 | M6 M6 | M7 | M8 | M10 2,5 ÷ 9 mm Ć25 x 9 mm
| M7, M8, M10 | M12 0,4 ÷ 6 mm 4 x 90 mm
| M14 | M16 | M20 Ć38 x 14: M12 | M14 | Nr 3: Ć38 x 14 mm
M16 | M20 4,9 ÷ 14 mm
DIMENSIONS 475 x 255 x 40 mm

WEIGHT 3,40 kg

CZD-85 HSS M3÷M2 4 INDEX Z1-085011-0000

Screw pitch Taps „T” type Distance
Taps Screwing dies Die stocks Screwdriver
gauge wrenches wrench ring
DIN-352 HSS - M3÷M12 9
DIN-352/2 HSS - M14÷M24 DIN-EN 22 568 HSS 800 MWGa PBPc PBGa RWWe
DIN-2181/2 HSS - MF 14x1,25
ł
CONTENTS

M3, M4, M5, M6, M8, M10, M3 | M4 | M5 | M6 | M8 | M10 Ć 25 x 9 mm
M12, M14, M16, M18, M12 | M14 | M16 | M18 Nr 2 zm.:
M20, M22, M24, M20 | M22 | M24 2,5 ÷ 9 mm Ć 38 x 14 mm Nr 1 38 x 2
M8x1, M10x1, M12x1,25, M8x1 | M10x1 | M12x1,25 0,4 ÷ 6 mm 4 x 90 mm 45 x 2
M12x1,5, M14x1,25, M14x1,5, M12x1,5 | M14x1,25 | M14x1,5 Nr 3: Ć 45 x 18 mm (M2 ÷ M5) 55 x 3
M16x1,5,M18x1,5, M20x1,5, M16x1,5 | M18x1,5 | M20x1,5 4,9 ÷ 14 mm
M22x1,5, M24x1,5 M22x1,5 | M24x1,5 Ć 55 x 22 mm
DIMENSIONS 550 x 380 x 70 mm

WEIGHT 12 kg

Example of order
203
Z1-040011-0000
CZD-40 HSS
