MF High performance machine taps MF

ISO Metric fine thread DIN-13 800
1 C B C-R40

0
60
H
HSSE
E
S
S
P
PM
P
M
l 1
HSSE
l 3
l 2
DIN
371
d 1 d 2 a

P M K P M K P M K
Material groups
N S H N S H N S H
Hole type
< 1.5d < 3d < 2,5d
Quality of material HSSE HSSE HSSE
Coating
Chamfer C / 2-3P B / 4-5P C / 2-3P
Norm DIN-371
MF
P l l 2 l a Tol. ISO2 (6H) ISO2 (6H) ISO2 (6H)
Ćd Tolerancja l 21 R40 3 Ćd 2
1
INDEX C2-121101 C2-111101 C2-511101
M3x0,35 0,35 56 10 5 18 3,5 2,7 2,65 0031
M3,5x0,35 0,35 56 10 5 20 4,0 3,0 3,15 0036
M4x0,5 0,50 63 12 7 21 4,5 3,4 3,50 0041
M5x0,5 0,50 70 14 8 25 6,0 4,9 4,50 0051
M6x0,75 0,75 80 14 10 30 6,0 4,9 5,20 0062
M8x0,75 0,75 80 18 10 30 8,0 6,2 7,20 0082
M8x1 1,00 90 20 13 35 8,0 6,2 7,00 0083
Tolerancja
M10x0,75 0,75 90 20 13 35 10,0 8,0 9,20 0102
M10x1 1,00 90 20 13 35 10,0 8,0 9,00 0103
M10x1,25 1,25 100 20 15 39 10,0 8,0 8,80 0104
ISO Vc (m/min)
P 5-20 5-20 5-20
M - - -
K 5-15 5-15 5-15
N 5-25 5-25 5-25
S - - -

Example of order Available from stock
40
C2-121101-0041 On request
Tap 800 M4x0,5-6H DIN-371 C HSSE
