G High performance machine taps G

Gwint metryczny ISO DIN-13
Whitworth pipe thread G, DIN-ISO 228 MASTERTAP
1 0 B-HL C-R45-HL
HSSE
H H H S 55 E
S
S
S
E
E
S
S
P
PM
M
M
P P P
M
l 1
HSSE l 2
PM
HSSE
HSSE
PM
PM
HL
d 1 d 2 a
DIN
5156
P M K P M K
Material groups
N S H N S H
Hole type
< 3d < 2,5d
Quality of material HSSE-PM HSSE-PM
Coating HL HL
Chamfer B / 4-5P C / 2-3P
Norm DIN-5156
MASTERTAP
G Ćd 1 1''/P P l 1 l 2 l Ćd 2 a Tol.
3
INDEX D4-118M01 D4-528M01
G1/16 7,723 28 0,907 90 10 6,0 4,9 6,80 3121
G1/8 9,728 28 0,907 90 10 7,0 5,5 8,80 3123
G1/4 13,157 19 1,337 100 14 11,0 9,0 11,80 3127
G3/8 16,662 19 1,337 100 15 12,0 9,0 15,25 3129
G1/2 20,955 14 1,814 125 17 16,0 12,0 19,00 3131
G5/8 22,911 14 1,814 125 20 18,0 14,5 21,00 3133
G3/4 26,441 14 1,814 140 20 20,0 16,0 24,50 3035
G7/8 30,201 14 1,814 150 22 22,0 18,0 28,25 3137
G1 33,249 11 2,309 160 24 25,0 20,0 30,75 3139

ISO Vc (m/min)
P 10-40 10-40
M 5-15 5-15
K 10-30 10-30
N 10-50 10-50
S 1-8 1-8

Example of order Available from stock
68
D4-528M01-3123 On request
Tap MasterTAP G-1/8'' DIN-5156 C HSSE-PM HL
