C-MAN

Computerized Maritime

Navigation system ASTRONAUTICS C.A. LTD.

For surface and sub-surface vessels P.O.Box 3351, Kiryat Arie

Features Monolithic Ring Laser Gyro INS/GPS Petah Tikva 4951207, Israel
navigation sensors or Tel: 972-3-9251555
Fax: 972-3-9251550

MEMS based INS sensors for Coastguard E-mail: astro@astro.co.il
Web Site: www.astronautics.co.il
and littoral Patrol Boat
C-MAN System Characteristics

Navigation Data Generation & Distribution

Heading

Attitude (Roll, Pitch)

Heading, Roll, Pitch rates

Velocity and speed (Relative to Water Mass)

Accelerations

Water depth

Wind speed and direction (Absolute and Relative)

Barometric Pressure

Turn key system solution for Integrated Relative Humidity
Navigation and inertial Data Distribution. Air temperature

Data computation and data distribution to all Reliability

shipboard sub-systems of all directions motion The C-MAN actual MTBF, per typical naval mission profile

sensing, attitude and position. is over 10,000 hours

Interface to Command & Control, Weapons,

Electro Optical Directors, Radar Antennas and all

ship’s inertial data users.

High accuracy, high reliability inertial sensor

with embedded GPS, accurate positioning at

minimal drift rates.

System redundancy:

Designed for full MEMS or RLG INS/GPS sensors

redundancy architecture.

Multiple outputs of Synchro and/or digital signals

to support multiple-outputs redundancy.

Flexibility and Modularity

Modular architecture allowing the use of any

combination of sensors (INS/GPS, EM/Doppler

Log, Echo sounder, Metrological center, etc.).

From basic low cost small vessels single sensor

system to high-end large surface vessels Operating and Control Consoles (OCC)
and advanced EP-Extended Performance Lowest Displays multiple video inputs
Drift submarines applications. High-speed synthetic graphics
Multiple outputs – supporting modern digital Networked display system
format sub-systems as well as analog/Synchro Built-in self-tests
shipboard systems. Excellent ergonomic configuration
Advanced Processing-utilizing Kalman Filters
optimized for naval navigation data, incorporates Designed to withstand harsh Naval environment conditions

accurate compensation and data filtering, taking

into account latency and utilizing unique prediction

algorithm considering the characteristics of naval

vessels.
