Page 187 - Deko-Light Light Impressions 2019-20
P. 187
COB 68 ACRYL
acrylic glass
dimensions H x Ø: 58,5 x 78 mm
dimmable via optional controller
power input: 8,00 W
energy efficiency class [EEI] spectrum A ++ to E
565247 colourless satined WW CW 2400-6500 K 590 lm EEI: A+
1
CV 24 8 W COB LED Ra>80 45° 68 43
accessories
930270 acrylic ring round | 90 mm
930271 acrylic ring angular | 90 x 90 mm
872633 power supply | 24V DC | 12 W
843023 RF-controller white
843031 Wifi-Box
COB 68 ACRYL
aluminium
dimensions L x H x Ø: 78 x 53,5 x 78 mm
dimmable via optionales power supply
power input: 6,50 W
energy efficiency class [EEI] spectrum A ++ to E
565195 colourless satined WW 2700 K 675 lm EEI: A++
565196 colourless satined NW 4000 K 730 lm EEI: A++
1
CC 350 mA 6,50 W COB LED Ra>80 30° 62 50
accessories
930270 acrylic ring round | 90 mm
930271 acrylic ring angular | 90 x 90 mm
180512 power supply | 350 mA | 18 W
872642 power supply dimmable | 350 mA | 9 W
186 INTERIOR LAMPS | recessed ceiling built-in lamps | fixed
