Page 193 - Deko-Light Light Impressions 2019-20
P. 193
LED PANEL 8
aluminium diecast
dimensions H x Ø: 18 x 145 mm
dimmable via optionales power supply
power input: 7,00 W
energy efficiency class [EEI] spectrum A ++ to E
565082 white WW 2700 K 590 lm EEI: A+
565083 silver coloured WW 2700 K 590 lm EEI: A+
565084 white NW 4000 K 610 lm EEI: A+
565085 silver coloured NW 4000 K 610 lm EEI: A+
24
CC 350 mA 17-18 7 W SMD LED Ra>80 115° 135 18
accessories
180512 power supply | 350 mA | 18 W
872642 power supply dimmable | 350 mA | 9 W
LED PANEL 12
aluminium diecast
dimensions H x Ø: 20 x 180 mm
dimmable via optionales power supply
power input: 9,00 W
energy efficiency class [EEI] spectrum A ++ to E
565088 white WW 2700 K 820 lm EEI: A+
565089 silver coloured WW 2700 K 820 lm EEI: A+
565090 white NW 4000 K 870 lm EEI: A+
565091 silver coloured NW 4000 K 870 lm EEI: A+
32
CC 350 mA 23-24 9 W SMD LED Ra>80 115° 169 20
accessories
180512 power supply | 350 mA | 18 W
872643 power supply dimmable | 350 mA | 12 W
192 INTERIOR LAMPS | recessed ceiling built-in lamps | fixed
