Page 211 - Deko-Light Light Impressions 2019-20
P. 211
LED PANEL PRO
aluminium
dimensions L x W x H: 1195 x 295x 10 mm
max. ceiling: 1,5 m
dimmable via optionales power supply
power input: 37,00 W
energy efficiency class [EEI] spectrum A ++ to E
100047 white WW 3000 K 3460 lm EEI: A+
100051 white NW 4000 K 3400 lm EEI: A+
CC 1050 35 37 W SMD 216 Ra>90 110°
mA
LED
accessories
872663 power supply | 1050 mA | 40 W
862022 power supply dimmable | 1050 mA | 40 W
862145 power supply DALI dimmable | 1050-1400 mA | 50 W
LED PANEL PRO
aluminium
dimensions L x W x H: 1240 x 620 x 11 mm
max. ceiling: 1,5 m
dimmable via optionales power supply
power input: 50,00 W
energy efficiency class [EEI] spectrum A ++ to E
100056 white WW 3000 K 4700 lm EEI: A+
100057 white NW 4000 K 4800 lm EEI: A+
CC 1300 35 50 W SMD 216 Ra>90 110°
mA
LED
accessories
862046 power supply dimmable | 1300 mA | 50 W
862145 power supply DALI dimmable | 1050-1400 mA | 50 W
210 INTERIOR LAMPS | recessed ceiling built-in lamps | fixed
