Page 429 - Deko-Light Light Impressions 2019-20
P. 429
POWER SPOT IX RGB
aluminium diecast
dimensions L x W x H: 235,6 x 182 x 66,2 mm
dimmable via optional controller
power input: 34,50 W
energy efficiency class [EEI] spectrum A ++ to E
732009 anthracite RGB 990 lm EEI: A
24 34,50 W 12 30° 3 CH IP65
LED
accessories
872660 power supply | 24V | 50 W | IP20
872619 power supply | 24V | 75 W | IP67
843024 RF colour remote controller dimmable | 12-24V DC | max. 360 W
843335 DMX LED dimmer 3 dimmable | 12 - 24V DC
843010 DALI 4 channel PWM dimmer | 12 - 24V DC
suitable dimmers and controllers from page 692
suitable Weipu cable systems from page 772
suitable outdoor mounting material from page 783
POWER SPOT IX WW
aluminium diecast
dimensions L x W x H: 237 x 165 x 46 mm
power input: 18,70 W
energy efficiency class [EEI] spectrum A ++ to E
732008 anthracite WW 3000 K 1440 lm EEI: A+
220-240 16 W 12 Ra>80 25° IP65/
LED IP44
suitable outdoor mounting material from page 783
428 OUTDOOR LAMPS | surface mounted spotlight
