Page 614 - Deko-Light Light Impressions 2019-20
P. 614
SAGITTAE LED PROFILE COMPLETE SET IP67
Material: Aluminum
Connection Stripe: 2 cable [V-, V+]
Incl. 1m connection cable with Weipu plug
dimmable via optional controllers
730451 3000 K 96 LEDs 5,3 W 190 lm 1000 x 27 x 30 mm EEI: A
730452 3000 K 192 LEDs 18 W 340 lm 2000 x 27 x 30 mm EEI: A
Connection Stripe: 5 cable [R, G, B, W, V+]
730453 3000 K | 460 - 620 nm 192 LEDs 22 W 190 lm 1000 x 27 x 30 mm EEI: A
730456 3000 K | 450 - 630 nm 384 LEDs 42 W 340 lm 2000 x 27 x 30 mm EEI: A
24 SMD
3528 100° Ra>80 IP67
Accessory for SAGITTAE Complete-Set
990109 Foam support
126 x 2,6 x 3 cm
Plastic | Hard foam
ALUMINUM PROFILES | Complete Sets 613
