Page 696 - Deko-Light Light Impressions 2019-20
P. 696
WIFI BOX
This WiFi box offers other control options via app for smart-
phones and tablets. In this way, the RF Mixit sets, RF controlls
and the RF LED bulbs can be controlled simultaneously via
remote control and smartphones / tablets.
dimensions L x W x H: 90 x 65 x 15 mm
incl. 230V / USB-Stromadapter
843031
5 500 2,4
mA GHz
KAPEGO RF CONTROLLER SET KAPEGO RF CONTROLLER SET
COLOR COLOR & WHITE
for controlling RGB end devices for controlling RGB + white end devices
set consists of: set consists of:
controller box, remote control und wall bracket controller box, remote control und wall bracket
R, G, B single dimmable R, G, B und white single dimmable
13 effect programs 12 effect programs
speed setting speed setting
connection control: R V+, G V+, B V+ connection control: R,G,B, V+, W, V+
dimensions L x W x H: 110 x 52 x 20 mm dimensions L x W x H: 110 x 52 x 20 mm
power: 180W at 12V DC | 360W at 24V DC power: 180W at 12V DC | 360W at 24V DC
843024 843025
12-24 2,4 3 12-24 2,4 4
CV CV
GHz GHz
accessories for 843024 accessories for 843025
843153 controller 843154 controller
843016 remote control 843017 remote control
843013 wall bracket 843013 wall bracket
843031 Kapego WiFi-Box 843031 Kapego WiFi-Box
CONTROLLER | RF-controller | 1 - 4 channel 695
