House of t H e future
                                                                               ROOF CONSTRUCTION
            FM and TV antenna feeds
                  into an integrated   Photovoltaic panel               Sedum turf
                 multimedia network    generates electricity


             Solar collector                      Security light  Mineral wool
               heats water

                                                              Timber trellis

            Automatic                                  Root-proof  membrane
          louvers to cool
             sun room
                                                             Polyurethane
                                                                insulation


                                                                           Vapor
                                                                          barrier

                                                                                                  Plywood
                                                                                                  roof  deck

                                                                       Window to upper
                                                                       floor home office

                                                                   Timber bay
                                                                   window to living
                                                                   and dining area
                                                                                   Earth bank insulates
                                                                                   lower floor

                                                                                        Blinds that open and
                                                                                        close automatically in
                                                                                        response to sunshine



























                                                                           SUN ROOm INTERIOR
