● evaluate the voltage regulation and efficiency for the transmission lines.
● analyze the voltage distribution in insulator strings and cables
● realize the mechanical design of transmission line and sag calculations.

TEXT BOOKS:
1. D.P.Kothari, I.J. Nagrath, “Power System Engineering”, Tata McGraw-Hill Publishing Company
limited, New Delhi, Second Edition, 2008.
2. C.L.Wadhwa, “Electrical Power Systems”, New Academic Science Ltd, 2009.
3. S.N. Singh, “Electric Power Generation, Transmission and Distribution”, Prentice Hall of India
Pvt. Ltd, New Delhi, Second Edition, 2011.

REFERENCES:
1. B.R.Gupta, S.Chand, “Power System Analysis and Design” New Delhi, Fifth Edition, 2008
2. Luces M.Faulkenberry ,Walter Coffer, “Electrical Power Distribution and Transmission”,
Pearson Education, 2007.
3. Hadi Saadat, “Power System Analysis”, PSA Publishing; Third Edition, 2010.
4. J.Brian, Hardy and Colin R.Bayliss, “Transmission and Distribution in Electrical Engineering”,
Newnes; Fourth Edition, 2012.
5. Kankar Bhattacharya, Jaap E. Daadler, Math H.J. Boolen, “Operation of restructured power
systems”, Kluwer Academic Pub., 2001.
6. Stuart Borlase, “Smart Grid :Infrastructure, Technology and Solutions”, CRC Press 2012.

EE 17404 CONTROL SYSTEMS L T P C
2 2 0 3

OBJECTIVES:
 To understand the use of transfer function models for the analysis physical systems and to
introduce the control system components.
 To provide adequate knowledge in the time response of systems and steady state error analysis.
 To accord basic knowledge in obtaining the open loop and closed–loop frequency responses of
systems.
 To introduce the concept of stability analysis.
 To introduce the importance of compensator and design of different kinds of compensators.

UNIT I SYSTEMS AND THEIR REPRESENTATION 12
Basic elements in control systems – Open and closed loop systems – Transfer function –mathematical
model of mechanical and electrical system – AC and DC servomotors, Synchros – Electrical analogy of
mechanical system– Block diagram reduction techniques – Signal flow graphs.

UNIT II TIME RESPONSE 12
Types of test signal –Time response of I and II order system – Time domain specifications-Steady state
error – Error coefficients – Generalized error series – Effects of P, PI, PID modes of feedback control

UNIT III FREQUENCY RESPONSE 12
