EXTRA HEAVY DUTY DIE RACK SHELVING 3000 lb. shelf capacity

Up to 15,000 Lb.
Capacity Shelving

2”
CHANNEL
REINFORCED SHELF
39”H Workbench
These 14 gauge steel shelves hold heavy items such as jigs, fixtures, dies, and more. Rigid 2” x
2”, 14 gauge angle posts. Reinforced shelves with flanged channel construction are adjustable on
1” increments. 3,000 lb. shelf capacity. Gray enamel finish. Easy assembly.

3’ HIGH 5’ HIGH 6’ HIGH 8’ HIGH ADDITIONAL
3 SHELF UNIT 4 SHELF UNIT 5 SHELF UNIT 6 SHELF UNIT SHELF
W”x D” Model Model Model Model Model
36 x 18 SC968600 SC968720 SC236602 SC236632 SC236662
48 x 18 SC968601 SC968721 SC236606 SC236636 SC236666
60 x 18 SC968602 SC968722 SC236608 SC236638 SC236668
36 x 24 SC968603 SC968723 SC236610 SC236640 SC236670
48 x 24 SC968604 SC968724 SC236614 SC236644 SC236674
60 x 24 SC968605 SC968725 SC236616 SC236646 SC236676
72 x 24 SC968606 SC968726 SC236618 SC236648 SC236678
BOLTLESS “BUILD YOUR OWN”
HEAVY EXTRA HIGH STEEL SHELVING
DUTY Customize to your storage needs. Order
SHELVING a minimum of 2 side by side shelving
units for stability. Start with 2 upright
assemblies, rear sway braces for Up to
stability and desired amount of shelves 16’ High
for storage. Add 1 additional upright
assembly; add sway braces and shelves
4000 lb. for each shelving unit until overall desired
width is met. Epoxy coat sand finish.
Capacity Upright Assembly includes two 16 gauge
steel posts with 18 gauge anti-sway side
per Shelf braces. Uprights greater than 8’H include
2 anti-sway braces. Allows shelf height
adjustments at 2” increments. 18 gauge
Rear Sway Braces are riveted together in
center for added rigidity. 2 or more pairs
of rear braces are required for units over
8’H. 22 gauge welded Steel Shelves offer
500 lb. capacity and are box formed for
added strength. Choose Plain shelves with
a solid surface or Perforated shelves to
allow light, air and sprinkler penetration.
UPRIGHT ASSEMBLY
H’ Model
7 SC968611
Extra strength boltless shelving units withstand dies, fixtures, jigs and other 8 SC968612
heavy material. Made using heavy duty steel with a powder coat finish. 16 10 SC968613 Up To
gauge steel shelves are reinforced with 14 gauge double rivet steel beams for 12 SC968614
maximum strength. Includes 5 height adjustable shelves that adjust at 1 1/ 2” 14 SC968615 16’ High
increments. 14-gauge formed angle uprights provide strength and rigidity. 16 SC968616
Boltless shelving is easy to assemble without the use of nuts, bolts or tools.
Cap. 7’ HIGH Cap. 8’ HIGH SHELF: Specify Solid (S) or Perforated (P) Suffix
W”x D” Lbs. Model W” x D” Lbs. Model SHELVES
36 x 18 4000 SC246301 36x18 4000 SC246309 (S) SOLID (P) PERFORATED REAR SWAY BRACE
48 x 18 4000 SC246302 48x18 4000 SC246310 W”x D” Model Cap. lbs. Cap. Lbs. W” Model
48 x 24 4000 SC246303 48x24 4000 SC246311 36 x 12 SC968617 750 550 36 SC968629
60 x 24 3250 SC246304 60x24 3250 SC246312 36 x 18 SC968618 750 550 48 SC968630
72 x 24 2750 SC246305 72x24 2750 SC246313 36 x 24 SC968619 700 525 --- ---
96 x 24 2600 SC246307 96x24 2600 SC246315 48 x 12 SC968620 500 375 --- ---
72 x 36 2750 SC246306 72x36 2750 SC246314 48 x 18 SC968621 500 375 --- ---
96 x 36 2600 SC246308 96x36 2600 SC246316 48 x 24 SC968622 450 335 --- ---
