Page 200 - US ACCESSORIES GUIDE (2019)

MERCRUISER

ANODE-HANGING
ANODES - PROPELLER
PROP NUT ANODE KIT

809690A 1
Aluminum
Provides additional corrosion protection when boat is at mooring. Fits all
applications when hung over side of the boat. 809664A 1
1‑1/8 in. Shaft, 3/4 in. NF 16
ANODES - DRIVESHAFT HOUSING Fits Mercury/Mariner 70 hp and higher outboards (except 225 EFI FourStroke);
Also fits MC‑I, R, MR, Alpha, Bravo One & TRS sterndrives (1970 & newer)
DRIVESHAFT HOUSING ANODE PROP NUT ANODE KIT MERCRUISER

821629T 1 809666A02
Aluminum Aluminum, For use in saltwater or freshwater.
Fits Alpha One Gen II drives. 1‑3/8 in. Shaft, 1 in. NF 14
Fits Bravo III drives (s/n 0M179451 and below)
Mercury Branded, Clamshell Package Point of Sale Packaged.
809666A03
821629Q 1 Magnesium, For use in freshwater only.
Aluminum 1‑3/8 in. Shaft, 1 in. NF 14
Fits Alpha One Gen II drives. Fits Bravo III drives (s/n 0M179451 and below)
Quicksilver Branded, Clamshell Package Point of Sale Packaged.
REPLACEMENT PROP NUT ANODE
821629A 2
Magnesium ‑ For freshwater use only. Do not use in saltwater applications.
Fits Alpha One Gen II drives.
DRIVESHAFT HOUSING ANODE

809662T
2 in. Aluminum Anode Shell
Replacement Shell for 809662A 1

821630T 1
Aluminum
Fits Bravo I, II, III, X XR & XZ drives.
Mercury Branded, Clamshell Package Point of Sale Packaged.
821630Q 1
Aluminum
Fits Bravo I, II, III, X, XR & XZ drives.
Quicksilver Branded, Clamshell Package Point of Sale Packaged.
821630A 2
Magnesium ‑ For freshwater use only. Do not use in saltwater applications.
Fits Bravo I, II, III, X, XR & XZ drives

2019 US Accessories Guide 187
