P. 478

ANALOG INSTRUMENTS



             VESSEL ANALOG GAUGE INTERFACE (AGI) KIT             SMARTCRAFT PITOT SENSOR KIT                          ANALOG INSTRUMENTS













                  892486K05                                           8M0090447
             For installations using analog gauges instead of SmartCraft.  Use with analog tab  Pitot sensor kit provides speed information for SmartCraft gauges.
             position (port & starboard), fuel level (two fuel tanks) and trim position gauges.  2.1L F75‑115 Four Stroke and 150 Four Stroke
             Enhanced Voltage Suppression.
             Race MerCruiser engines with the 14 pin Deutsch connector engine wiring
             harness. One AGI kit per boat required.             MONITOR PANELS FOR DIESELS
             TROLL CONTROL- DASH MOUNTED- ANALOG
                                                                 PRIMARY STATION MONITOR PANEL












                87-8M0083439                                          806385T
             Troll Control will allow you to have the same functions that you get from the
             SmartCraft Digital gauges and adjust the speed of the boat.  By pushing the button  Warning lights are provided for low oil pressure, excessive coolant temperature,
             up or down, you can feather your speed every 10 RPM.  Go from idle to 1000 RPM  insufficient alternator output and glow plug activation.
             or anywhere in between. (some engine can actually go lower than idle (75‑115 4  Fits 1.7L MS & MI 120 and 4.2 MS & MI (200 & 230)
             stroke(Walleye), 135‑200 HP Verado   4 cylinder and 3.0L Optimax)  This kit will be
             used in analog gauge installations.  RPM will reset to idle when more than 2‑3%  PRIMARY STATION MONITOR PANEL
             movement occurs at the throttle (TPS)
             Can be used with any Analog  Gauge installation without a J Box.  "Y" harness is
             included in kit to connect to main engine hanress.  This kit can be used with any
             SmartCraft compatable Mercury Engine.
             CONVERSION KIT - SMARTCRAFT SENSORS






                                                                      861014
                                                                 Warning lights are provided for low oil pressure, excessive coolant temperature,
                                                                 insufficient alternator output, glow plug activation & check engine light.
                                                                 Fits 1997 and newer 2.8 ES & EI 165 and 4.2 ES & EI (250 & 230)
                  889250K01
             New kit that allows you to use SmartCraft gauges on these engines
             Gen II (2007) 75 HP ‑ 115 HP 4 stroke 1.7L engines
















             2019 US Accessories Guide                                                                      465
