P. 653
ELECTRICAL
SMARTCRAFT J-BOX TERMINATOR/RESISTOR PLUG ASY DIAGNOSTIC PORT
ELECTRICAL
859318T 1 8M0046339
SmartCraft Yellow 10‑pin Terminator/Resistor 10 pin diagnostic port for use on any SmartCraft application.
Provides CAN Bus termination for CAN P network. Used as a 10 pin diagnostic port for connecting Mercury Computer Diagnostic
859318B 1 System (CDS) junction box connection. Typically gets mounted at the helm, out of
line of sight so that a technician does not have to disassemble helm to plug into a
SmartCraft Yellow Junction Box Terminator/Resistor 10 pin connection. Requires a harness from back of diagnostic port to a 10 pin
Provides CAN Bus termination where installed SmartCraft connection in the rigging.
Priced individually, sold @ multiples of 24
TERMINATOR ASSEMBLY SECURITY SYSTEMS
This section will include security devices that will help protect your
engine against theft..
MERCURY THEFT DETERRENT SYSTEM (TDS) STAGE 1
8M0055652
SmartCraft Red Terminator Can 1/P & H
RESISTOR- TERMINATION- 2 PIN
8M0057383
Mercurys TDS improves boat and engine security and provides owner ease of
mind. The system immobolizes the engine until the Fob is inserted. (Limit to
approximately 2000 RPM) Once the Fob is inserted into the docking station; the
user will experience normal engine performance. Red or green lights on the
docking station indicates lock or unlock condition.
Can be used on ALL SmartCraft capable engines 40 HP and above (40‑60 4
stroke engines serial # 1C173334) all MCM DTS (2007 and newer ‑ serial
#1B381712) as well as Racing DTS (need Version 77 or newer MicroChi)
MERCURY TDS- PREMIUM
893388A01
Blue 2‑pin terminator/resistor
Provides CAN bus termination for CAN Networks.
HELM MPR 2 PIN WEATHER CAP
98-8M0065146
Kit that allows tracking of a boat using a satellite communication system. This
system notifies the owner via email or text if the boat has left its location or
exceeded the user definiable Geo Fence (which can be set to notify if it leaves a
known good area or notify it it enters a known bad area). It also allows you to use
a unique website that you can track the boat. Included in the kit is the immobilizer
86-8M0054244 that limits power if the fob is not engaged. (includes both the 8M0057383
Immobilizer kit and the 8M0059374 Premium Satelite Tracking Kit). System is CE
GT280 2 pin male weather cap. certified and can be installed in Europe.
Used on Joystick (Zeus, Axius and JPO) applications for the Helm MPR connection Can be used on all 40‑60 4 stroke engines (serial # break is 1C173334) and the
harness 8M2021476. new 150 4 Stroke engine. Can also be used on Verado and all MCM DTS 2007
( serial number 1B381712 and above) and newer as well as Racing DTS .
( Need Version 0077 Micro Chi or later)
