ELECTRICAL

TACHOMETER HARNESS
REMOTE CONTROL ADAPTER HARNESSES
REMOTE CONTROL ADAPTER HARNESS
ELECTRICAL

84- 69108A 5
Four pin style. Used with 84‑87364A__ series harnesses, 65640A__ series
controls and 76334A__ series controls.
84-892473A01
TACHOMETER HARNESS Converts the traditional Mercury connector to an Amp 8‑pin connector.
Converts side mount controls 881170A 3, 15, 16 and the 816626A_ series ignition
keyswitch harness to connect to the MY2005 and newer 8/9.9 hp. FourStroke
outboard.
MY2005 and newer 8/9.9 hp. FourStroke outboard and the 15/20 hp. FourStroke
(351cc) outboard when a 8 pin side mount control or keyswitch harness is used.
REMOTE CONTROL/IGNITION CHOKE EXTENSION
HARNESSES

Fits Mercury / Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin)
outboards, Mariner 30/40 hp. with oil injection (2 cycle, Japanese
84- 86396A 8 Origin), all Mercury / Mariner 4‑Stroke (USA Origin) outboards and
Five pin style. 4 ft.(1.2 m). Used with Commander, Commander 2000 series & MSC Force 40 hp. and Higher (1993 and Newer). Various applications
4000 (8 pin) series side mount controls and Ignition/Choke assemblies. include 7,8 and 10 pin harnesses and 12 wire (8 pin plus 4 bullet
84- 86396A24 connectors) used on side mount controls and ignition/choke assemblies.
Five pin style. 13 ft.(4 m). Used with Commander, Commander 2000 series & MSC
4000 series side mount controls and Ignition/Choke assemblies. EXTENSION HARNESS
TACHOMETER HARNESS

84- 17829A 2
2 ft.(0.6 m) harness, 8 lead harness.
84-827593A 2 Used as harness extension or to complete two station installations.
Bullet pin style. 84- 17829A10
Fits Mercury/Mariner 30 to 90 electric start tiller handle models.
10 ft.(3.05 m) harness, 8 lead harness.
Used as harness extension or to complete two station installations.
84- 17829A20
20 ft.(6.1 m) harness, 8 lead harness.
Used as harness extension or to complete two station installations.
