Page 724 - US ACCESSORIES GUIDE (2019)

STEERING

Model Year Range Model Notes Country Serial # Range Stbd. Cable Entry Steering Port Cable Entry Steering Required Steering Bracket
Link Rod Attaching Kit Link Rod Attaching Kit
30 FourStroke (EFI) 2006 - 2019 Only manual start models JPN 0R106999 and up 898101A45 N/A(4) 898101189(5)
require steering bracket
30 FourStroke (EFI) 2006 - 2019 Only manual start models BEL 0P401000 and up 898101A45 N/A(4) 898101189(5)
require steering bracket
40 FourStroke (3 cylinder) 1999 - 2007 Only manual start models USA 0T409000 - 1B344398 19608A14 893696(2)
require steering bracket
40 FourStroke (3 cylinder) 2007 - 2019 Only manual start models CHN 1C000001 and up 19608A14 893696(2)
require steering bracket
40 FourStroke (4 cylinder) 2001 - 2007 BigFoot gearcase 996 cc. USA 0T178500 - 1B344306 19608A14 19609A 6 816667A 2(2)
40 FourStroke (4 cylinder) 2001 - 2007 BigFoot gearcase 996 cc. BEL 0P094500 and up 19608A14 19609A 6 816667A 2(2)
40 FourStroke (4 cylinder) 2007 - 2019 CHN 1C000001 and up 19608A14 19609A 6 816667A 2(2)
50 FourStroke (4 cylinder) 2001 - 2007 996 cc. USA 0T178500 - 1B344306 19608A14 19609A 6 816667A 2(2)
50 FourStroke (4 cylinder) 2001 - 2019 996 cc. BEL 0P094500 and up 19608A14 19609A 6 816667A 2(2)
50 FourStroke (4 cylinder) 2007 - 2019 CHN 1C000001 and up 19608A14 19609A 6 816667A 2(2)
60 FourStroke 2001 - 2007 996 cc. USA 0T178500 - 1B344306 19608A14 19609A 6 816667A 2(2)
60 FourStroke 2001 - 2019 996 cc. BEL 0P094500 and up 19608A14 19609A 6 816667A 2(2)
60 FourStroke 2007 - 2019 CHN 1C000001 and up 19608A14 19609A 6 816667A 2(2)
75-115 FourStroke 2007 - 2019 USA 1B366823 and up 92876A12 N/A N/A
75-115 FourStroke 2007 - 2019 BEL 0P401000 and up 92876A12 N/A N/A
135 thru 275 (V-6) 1980 - 2019 USA 5464486 and up 92876A12 N/A N/A
150 EFI FourStroke 2011 - 2019 USA 1B905505 and up 92876A12 N/A N/A STEERING
135-200 Verado (4 2006 - 2019 USA 1B227001 and up (6)
cylinder)
200-300 Verado (6 2005 - 2019 USA 0T980000 and up (7)
cylinder)
(1) Bracket part number listed is without carrying handle.
(2) Bracket already furnished on remote models.
(3) When using port entry Ezy Glide stick steering, order attaching kit 41323A 2.
(4) When using port entry Ezy Glide stick steering, order attaching kit 899659A01.
(5) Steering bracket is part of the steering link rod attaching kit.
(6) Hydraulic Steering is standard.
(7) Power Steering is standard.

DUAL CABLE - SINGLE ENGINE ATTACHING KIT DUAL ENGINE TIE BAR KITS

Tension‑compression only with both cables installed on the starboard Dual cables are required for installations of 80 hp. (combined total of
side. 160 hp.) or higher.

DUAL CABLE ATTACHING KIT TIE BAR EXTENSION

92876A 8 8M0026098
Fits Mercury / Mariner 70‑300 hp. outboards (1985 and Newer) and Force 90/120 Standard Tie Bar Extension Coupler. 15 in.(381 mm). For clearance problems see
hp. outboards (1996 and Newer). optional extension couplers.
Fits Mercury/Mariner with standard cowling clearance. Outboard center line
distance between 23‑1/2 in. thru 27‑1/2 in. (597 mm thru 699 mm)

2019 US Accessories Guide 711
