Page 924 - US ACCESSORIES GUIDE (2019)

HISTORICAL PROPELLER CHARTS

MERC 18 & 25 (Standard Propellers) PART NO. DIAMETER PITCH MATERIAL BLADES ROTATION
Thrust Hub 858498 Nut 11‑88228 19638A40 10-3/8 11C AL 3 RH
43582A10 10-3/8 9-1/2 AL 3 RH
PART NO. DIAMETER PITCH MATERIAL BLADES ROTATION
89850A 1 10-3/8 9-1/2 AL 3 RH
43590A40 10-1/4 14-1/2C AL 3 RH
19636A10 10-3/8 9-1/2 AL 3 RH
89854A 4 10-1/4 14-1/2C AL 3 RH
19642A40 10-3/8 14-1/2C AL 3 RH
43586A40 10-3/8 13C AL 3 RH MERC 18 & 25 (Chopper Propellers)
86848A 4 10-3/8 13C AL 3 RH Thrust Hub 858498 Nut 11‑88228
19640A40 10-3/8 13C AL 3 RH
43588A 5 10-3/8 13C SS 3 RH
PART NO. DIAMETER PITCH MATERIAL BLADES ROTATION
90780A 4 10-3/8 13C SS 3 RH
92764A 4 10-3/8 18C SS 3 RH
19644A 5 10-3/8 13C SS 3 RH
92764A 5 10-3/8 18C SS 3 RH
43584A40 10-3/8 11C AL 3 RH
43592A61 10-3/8 18C SS 3 RH
89852A 4 10-3/8 11C AL 3 RH
Mercury 200 (20HP)
MERC 200 (20Hp) 1963‑1979
8 Tooth Spline
Thrust Hub 23‑85964A1, Spacer 23‑85964A1, Nut 11‑64075A1

Length Current MPH Propeller Size Material Blades Style Quicksilver P/N OEM P/N Hub System
To 14' 18-22 9-7/8 X 11 RH AL 2 Black Diamond N.L.A. N.L.A. Rubber Bushing
14-16 up to 20 10 X 9 RH AL 3 Black Diamond N.L.A. N.L.A. Rubber Bushing
MARK 28/28A & MERC 200/250 AUTO. TRANS.

PART NO. DIAMETER PITCH MATERIAL BLADES ROTATION STATUS
28036A 1 N.L.A.
28037A 1 N.L.A.
28038A 1 N.L.A.
MARK 50 & 55 (14 SPLINE HUB)

PART NO. DIAMETER PITCH MATERIAL BLADES ROTATION STATUS
22105A 1 N.L.A.
22575A 1 N.L.A.
22636A 1 N.L.A.
22814A 1 N.L.A. HISTORICAL PROPELLER CHARTS
22914A 1 N.L.A.
23586A 1 N.L.A.
23587A 1 N.L.A.
26666A 1 N.L.A.
27028A 1 N.L.A.
MARK 35A/55/55A/58/58A & MERC 300/350/400/500
(11 SPLINE HUB, NON‑THRU HUB EXHAUST)

PART NO. DIAMETER PITCH MATERIAL BLADES ROTATION STATUS
22105A 2 N.L.A.
22575A 2 N.L.A.
22636A 2 N.L.A.
22814A 2 N.L.A.
22914A 2 N.L.A.
23586A 2 N.L.A.
23587A 2 N.L.A.
25773A 2 N.L.A.
26666A 2 N.L.A.

2019 US Accessories Guide 911
