OMC STERN DRIVE/COBRA PROPELLER PRODUCTS
OMC STERN DRIVE/COBRA PROPELLER PRODUCTS
PROPELLER CHARTS
Engine Model to Propeller Family
Select the correct Propeller Family based on the Engine models below.
Then continue to the Propeller selection chart.
Model Year Range Propeller Family O.E. P/N Quicksilver # Material Blades Notations
2.3L 120-128 Hp 1978 - 1990 A 382761 N.L.A. AL 3 Rubber Hub
2.5L 120 Hp 1978 - 1989 A 391668 N.L.A. AL 3 Rubber Hub
3.0L 130-140 Hp 1978 - 1989 A 391198 N.L.A. AL 3 Rubber Hub
400 Series 1978 - 1985 A 391199 N.L.A. AL 3 Rubber Hub
Cobra 1986 - 1993 A 176214 N.L.A. AL 3 Rubber Hub
3.0L 1990 - 1993 B 390896 N.L.A. AL 3 Rubber Hub
3.2L Diesel 1992 - 1993 B 176215 N.L.A. AL 3 Rubber Hub
3.8L 1978 - 1993 B 389788 N.L.A. AL 3 Rubber Hub
4.3L 1985 - 1993 B 176216 N.L.A. AL 3 Rubber Hub
5.0L 1978 - 1993 B
5.7L 1978 - 1993 B PRODUCTS OMC STERN DRIVE/COBRA PROPELLER
5.8L 1978 - 1993 B
7.4L 1987 - 1993 B
7.5L 1987 - 1993 B
454 King (7.4L) 1990 - 1993 B
502 King (8.2L) 1990 - 1993 B
600&800 Series 1978 - 1985 B
Cobra 1986 - 1993 B
King Cobra 2019 B
15 Spline Prop Shaft 2019 B
1.6L V-4 1983 - 2019 C
1.8 L V-4 1983 - 2019 C
2.0L V-4 1982 - 1991 D
2.5L V-6 1982 - 1987 D
2.6L V-6 1982 - 1986 D
2.7L V-6 1987 D
3.0L V-6 1988 - 1991 D
3.6L V-8 1987 D
4.0L V-8 1989 - 1991 D
Propeller selection Chart
Based on the propeller family on the previous chart, select your propeller from the associated propeller family.
Counter Rotation ‑ Left Hand Propellers ‑ add 4" of pitch to propeller for twin engine installation.
Propeller Family Size Rotation O.E. P/N Quicksilver # Material Blades Notations
A 14 X 11 RH 382761 N.L.A. AL 3 Rubber Hub
A 14 X 13 RH 391668 N.L.A. AL 3 Rubber Hub
A 13-3/4 X 15 RH 391198 N.L.A. AL 3 Rubber Hub
A 13-1/4 X 17 RH 391199 N.L.A. AL 3 Rubber Hub
A 14 X 17 RH 176214 N.L.A. AL 3 Rubber Hub
A 13 X 19 RH 390896 N.L.A. AL 3 Rubber Hub
A 14 X 19 RH 176215 N.L.A. AL 3 Rubber Hub
A 12-3/4 X 21 RH 389788 N.L.A. AL 3 Rubber Hub
A 14 X 21 RH 176216 N.L.A. AL 3 Rubber Hub
A(1) 13-1/8 X 16 RH 389949 SS 3 Flo-Torq II Hub
A(1) 13 X 18 RH 176572 SS 3 Flo-Torq II Hub
