QUICK REFERENCE GUIDE-OUTBOARD

Description Part Number Page

Flushing Attachment - allows running engine - Q/S 44357Q 2 173

25‑30 Hp EFI FourStroke 0R106999 & above

Description Part Number Page

Controls

Side Mount - MSC 4000 Series - Electric w/trim 15 ft. (4.6 m) harness, Gen II 8M0083666
20 ft. (6.1 m) harness, Gen II 8M0083667
Extra 6 ft. Extension (10 pin) 84-8M0058668 533

Dual Engine Remote Control Kit (for side mount control stacking) 16909A 2 536

Panel Mount (non-trim) - MPC 4000 Series (Gen II) Finger Release - Black Handle 8M0011212 528
Lock Bar 883710A01 529

Panel Mount (with trim) - MPC 4000 Series (Gen II) Finger Release - Black Handle 8M0011213 528
Finger Release - Chrome Handle 8M0030550 528
Lock Bar 883710A02 529

Console Mount (single eng. w/o-trim) - MCC 4500 Gen II 8M0060782 530
Console Mount (single eng. with trim) - MCC 4500 Gen II 8M0059686 530

Console Mount (dual eng. w/o-trim) - MCC 4500 Gen II 8M0075244 531
Console Mount (dual eng. with trim) - MCC 4500 (Gen II) - single trim switch in handle 8M0075245 531

Throttle/Shift Cables (two per engine) - (Gen I) (Premium Series) 897977A03 thru 897977A04 554
QUICK REFERENCE GUIDE-OUTBOARD 25 Hp. Max WOT range = 5,000-6,000 RPM's White Face 79-895283A43 488
8M0082526
thru
8M0082553
(Premium Series)
Throttle/Shift Cables (two per engine) - (Gen II)

Instrumentation

30 Hp. Max WOT range = 5,250-6,250 RPM's

Tachometer - 6000 RPM - Flagship
79-895283Q03
492
Tachometer - 6000 RPM - Admiral
Black Face

619
84-892990T01
Tachometer Harness - Analog - 5ft.
Use with 14 pin Side Mount Controls or harnesses.
84-892990T10
Tachometer Harness - Analog - 10 ft. White Face 79-895283Q23 500
Use with 14 pin Side Mount Controls or harnesses.
619
Tachometer Harness - Analog - 15 ft. Use with 14 pin Side Mount Controls or harnesses. 84-892990T15 619

Speedometer - 10/45 MPH - Flagship White Face 79-895285A41 488
Speedometer - 10/45 MPH - Admiral Black Face 79-895285Q01 493
White Face 79-895285Q21 500

Battery Meter - Flagship White Face 79-895286A41 489
Battery Meter - Admiral Black Face 79-895286Q01 494
White Face 79-895286Q21 501

Fuel Gauge - Flagship White Face 79-895291A41 491
Fuel Gauge - Admiral Black Face 79-895291Q01 495
