MECHANICAL REMOTE CONTROLS

CONTROL LEVER W/ TRIM DIODE KIT

848924A 7 812497A 5
Starboard mounted/ Black/ AFT CANT/ (w/ trim). Updates standard control to trim Prevents feedback in the down trim circuits between multiple engines. Also need to
switch feature. Diode kit is needed when updating from controls with no trim order Diode Kit 812497A 6.
switches, to levers with trim switches on multiple engine boats. See Diode Kits. Required and only used on boats with "triple" engines when updating zero effort
CONTROL LEVER W/ TRIM control levers without trim switches to levers with trim switches.
DIODE KIT

848924A 8
Starboard mounted/ White/ AFT CANT/ (w/ trim). Updates standard control to trim 812497A 6
switch feature. Diode kit is needed when updating from controls with no trim Prevents feedback in the up trim circuits between multiple engines. Also need to
switches, to levers with trim switches on multiple engine boats. See Diode Kits. order Diode Kit 812497A 5.
DIODE KIT Required and only used on boats with "triple" engines when updating zero effort
control levers without trim switches to levers with trim switches.
REMOTE CONTROL CONVERSION KITS

REMOTE CONTROL CONVERSION KIT

812497T03
Prevents feedback in the down trim circuits between multiple engines. Also need to
order Diode Kit 812497A 4.
Required and only used on boats with "dual" engines when updating zero effort
control levers without trim switches to levers with trim switches.
DIODE KIT 895284A01
Converts an electric start tiller handle outboard to an electric start remote throttle
and shift operation. Suitable controls, throttle/shift cables and keyswitch harnessing
are additionally required. The appropriate carburetor and the steering link rod
attaching hardware are included in the kit.
Fits 9.9 hp. FourStroke, Model Year 2005‑2006, both standard and BigFoot models
requiring SAE ended throttle/shift cables. Serial Numbers
JPN‑0R042475‑0R192771 & BEL‑0P325500‑0P513329.

812497A 4
Prevents feedback in the up trim circuits between multiple engines. Also need to
order Diode Kit 812497A 3. MECHANICAL REMOTE CONTROLS
Required and only used on boats with "dual" engines when updating zero effort
control levers without trim switches to levers with trim switches.
