P. 857
MERCURY RACING PROPELLER TYPE
48-8M0160122 48-8M0163492
15.25 x 32 Pitch RH 15 Rake 15.25 x 38 Pitch RH 15 Rake
48-8M0160123 48-8M0163493
15.25 x 33 Pitch LH 15 Rake 15.25 x 38 Pitch LH 15 Rake
48-8M0160856 48-8M0163514
14.75 x 34 Pitch RH 15 Rake 14.75 x 39 Pitch RH 15 Rake
48-8M0160857 48-8M0163513
14.75 x 34 Pitch LH 15 Rake 14.75 x 39 Pitch LH 15 Rake
48-8M0160858 48-8M0163516
15.00 x 34 Pitch RH 15 Rake 15.00 x 39 Pitch RH 15 Rake
48-8M0160859 48-8M0163515
15.00 x 34 Pitch LH 15 Rake 15.00 x 39 Pitch LH 15 Rake
48-8M0160860 48-8M0163518
15.25 x 24 Pitch RH 15 Rake 15.25 x 39 Pitch RH 15 Rake
48-8M0160861 48-8M0163517
15.25 x 34 Pitch LH 15 Rake 15.25 x 39 Pitch LH 15 Rake
48-8M0155384 14.75 x 40 Pitch RH 15 Rake
48-8M0163522
MERCURY RACING PROPELLER TYPE 15.00 x 35 Pitch RH 15 Rake 15.00 x 40 Pitch RH 15 Rake
14.75 x 35 Pitch RH 15 Rake
48-8M0155383
48-8M0163521
14.75 x 35 Pitch LH 15 Rake
14.75 x 40 Pitch LH 15 Rake
48-8M0156788
48-8M0163524
48-8M0156787
48-8M0163523
15.00 x 40 Pitch LH 15 Rake
15.00 x 35 Pitch LH 15 Rake
48-8M0163526
48-8M0160826
15.25 x 35 Pitch RH 15 Rake
15.25 x 40 Pitch RH 15 Rake
48-8M0160827
48-8M0163525
15.25 x 36 Pitch LH 15 Rake
48-8M0155386
CNC OUTBOARD CLEAVER 500 HP 18 DEGREE
14.75 x 36 Pitch RH 15 Rake
RAKE
LAB FINISHED CNC OUTBOARD CLEAVER 15.25 x 40 Pitch LH 15 Rake
48-8M0155385
14.75 x 36 Pitch LH 15 Rake •The Lab Finished CNC Outboard Cleaver is designed to be the most
LAB FINISHED OUTBOARD CNC CLEAVER efficient propeller for high speed applications
•As opposed to a standard propeller, the CNC machining process offers
48-8M0159892 superior precision and replicability for all dimensions of the propeller
15.00 x 36 Pitch RH 15 Rake •18 degree rake is applicable for high speed vee bottoms and some
48-8M0159893 catamarans that require additional bow lift
15.00 x 36 Pitch LH 15 Rake •Broched splines for 1.25 inch prop shaft, designed for 450R outboard
48-8M0159972 •Additional dimensions are available for custom order
15.25 x 36 Pitch RH 15 Rake
48-8M0159973 LAB FINISHED OUTBOARD CNC CLEAVER
15.25 x 36 Pitch LH 15 Rake
48-8M0157712
14.75 x 37 Pitch RH 15 Rake
48-8M0157711
14.75 x 37 Pitch LH 15 Rake
48-8M0160038
15.00 x 37 Pitch RH 15 Rake
48-8M0160037
15.00 x 37 Pitch LH 15 Rake
48-8M0160040
15.25 x 37 Pitch RH 15 Rake 48-8M0159956
48-8M0160039 14.75 x 26 Pitch RH 18 Rake
15.25 x 37 Pitch LH 15 Rake 48-8M0159955
48-8M0163488 14.75 x 26 Pitch LH 18 Rake
14.75 x 38 Pitch RH 15 Rake 48-8M0154970
48-8M0163489 15.00 x 26 Pitch RH 18 Rake
14.75 x 38 Pitch LH 15 Rake 48-8M0154969
48-8M0163490 15.00 x 26 Pitch LH 18 Rake
15.00 x 38 Pitch RH 15 Rake 48-8M0160052
48-8M0163491 15.25 x 26 Pitch RH 18 Rake
15.00 x 38 Pitch LH 15 Rake 48-8M0160051
15.25 x 26 Pitch LH 18 Rake
848 Phone: 954-744-3500; Fax: 954-744-3535; E-Mail: miami@mercmarine.com
