MERCURY RACING PROPELLER CHARTS

Diameter Pitch Pro Finished LH Pro Finished RH Diameter Pitch Pro Finished LH Rotaion Pro Finished RH
Rotation Rotation Rotaion
15.25 26.5 Not Available 48-8M0128334 14.6 18 48-8M0113929 48-8M0113928
15.25 27 48-8M0071093 48-8M0064472 14.6 18.5 48-8M0113931 48-8M0113930
15.25 28 48-8M0071094 48-8M0064473 14.6 19 48-8M0113933 48-8M0113932
15.25 28.5 Not Available 48-8M0128335 14.6 19.5 48-8M0113935 48-8M0113934
15.25 29 48-8M0071095 48-8M0064475 14.6 20 48-8M0113937 48-8M0113936
15.25 30 48-8M0071096 48-8M0064476 14.6 20.5 48-8M0113939 48-8M0113938
15.25 31 48-8M0071097 48-8M0064477 14.6 21 48-8M0113941 48-8M0113940
15.25 32 48-8M0104418 48-8M0104417 14.6 21.5 48-8M0113943 48-8M0113942
15.25 33 48-8M0104420 48-8M0104419 14.6 22 48-8M0113945 48-8M0113944
15.25 34 Not Available 48-8M0157785 14.6 22.5 48-8M0113947 48-8M0113946
15.25 35 Not Available 48-8M0157786 14.6 23 48-8M0113949 48-8M0113948
15.25 36 Not Available 48-8M0157787 14.6 23.5 48-8M0113951 48-8M0113950
15.25 37 Not Available 48-8M0157788 14.6 24 48-8M0113953 48-8M0113952
14.6 24.5 48-8M0113955 48-8M0113954
ENERTIA ECO XP PROPELLER 14.6 25 48-8M0113957 48-8M0113956
14.6 25.5 48-8M0113959 48-8M0113958
14.6 26 48-8M0128847 48-8M0128846
14.6 26.5 48-8M0128850 48-8M0128849

REVOLUTION 4 LAB FINISHED PROPELLER

Enertia ECO XP Propeller Chart

Diameter Pitch LH Rotation RH Rotaion
16 16.5 48-8M0110303 48-8M0110304
16 17.5 48-8M0119053 48-8M0119052
16 18.5 48-8M0108351 48-8M0108350 Revolution 4 Lab Finished Chart
MERCURY RACING PROPELLER CHARTS REVOLUTION 4 XP PRO FINISHED PROPELLER Diameter Pitch Lab Finished LH Rotaion Lab Finished RH
48-8M0119056
19.5
48-8M0119055
16
48-8M0108353
20.5
16
48-8M0108352
48-8M0119057
48-8M0119058
16
21.5
48-8M0108354
16
22.5
48-8M0108357
Rotaion
48-857026L55
14.6
48-857027L55
19
48-8M0106547
14.6
20
48-8M0106548
48-857029L55
21
14.6
48-857028L55
22
48-8M0106546
14.6
48-8M0106545
48-857031L55
23
14.6
48-857030L55
48-8M0106544
14.6
48-8M0106543
24
48-857033L55
48-857032L55
14.6
25
Revolution 4 XP Pro Finished Chart
Diameter Pitch Pro Finished LH Rotaion Pro Finished RH
Rotaion
14.6 13 NA 48-8M0142110
14.6 14 48-8M0142111 48-8M0142112
14.6 15 48-8M0142113 48-8M0142114
14.6 16 48-8M0142115 48-8M0142116
14.6 17 48-8M0142117 48-8M0142118
