Page 981 - Latin America Accessories Guide (2020) - 8M0163252

PROPELLER HARDWARE AND ACCESSORIES

FLO-TORQ II HUB KIT YAMAHA FLO-TORQ II HUB KIT
835274Q 1
853948 1 Forward thrust washer
879637 Plastic drive sleeve
826074Q1 Aft adapter
887972 Spacer
859939 Nut
89961 Cotter Pin
150‑300 HP 4 stroke outboards and 115‑250 VMAX SHO outboards using OEM
single piece thrust washer
Use p/n 8M0075402 for 115‑250 VMAX SHO outboards using OEM two piece
thrust washer
835272Q 1 Quicksilver Branded, Hanging Box Point of Sale Packaged.
853555 Forward thrust washer FLO-TORQ REFLEX DRIVE SLEEVE
879637 Plastic drive sleeve
826074Q1 Aft adapter
850076 Spacer
859935 Nut
89961 Cotter Pin
Yamaha outboards (50‑100 HP, splined forward thrust washer)
Quicksilver Branded, Hanging Box Point of Sale Packaged.
FLO-TORQ II HUB KIT YAMAHA

8M0047148
Plastic drive sleeve Flo‑Torq Reflex Composite Drive Sleeve
DRIVE SLEEVE

835271Q 2
853948 Forward thrust washer
879637 Plastic drive sleeve
826074Q1 Aft adapter
850076 Spacer
859939 Nut
89961 Cotter Pin
Yamaha 150‑300 HP HPDI 2‑stroke outboards using a one piece thrust washer
and all Yamaha stern drives
Quicksilver Branded, Hanging Box Point of Sale Packaged.
835290Q 1
FLO-TORQ II HUB KIT YAMAHA Plastic drive sleeve Flo‑Torq II
Quicksilver Branded, Hanging Box Point of Sale Packaged.
DRIVE SLEEVE

8M0075402
8M0064826 Forward thrust washer Flo‑Torq III Spring Drive Sleeve
879637 Plastic drive sleeve
PROPELLER HARDWARE AND ACCESSORIES 115‑250 HP VMAX SHO 4 stroke outboards using a two piece thrust washer.
881940Q 1
826074Q1 Aft adapter
887972 Spacer
859939 Nut
For use with 40 ‑ 60 BigFoot, 75 ‑ 115 HP FourStroke outboards (Reduce prop
89961 Cotter Pin
rattle)
Use part number 835274Q1 if OEM hub uses single piece thrust washer
Quicksilver Branded, Hanging Box Point of Sale Packaged.
