Page 454 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

MERCURY RACING PROPELLER CHARTS

Diameter (Inches) Pitch LH Rotation RH Rotation CNC Cleaver, Heat Treated SS 6 Blade, 18 Degree Rake ‑ 900
18 37 48-8M0013911 48-8M0013912 HP
17.75 37 48-8M0013941 48-8M0013942 IIIA, IV, V, VI, VII SSM, NXT1, M8. Case 8M0107970 included.
17.5 37 48-8M0013971 48-8M0013972 26 Spline hub with 1.75/1.88 in.(44.5/47.7mm) O.D. propeller shaft and 6 in.
(152mm) hub length
17.25 37 48-8M0014001 48-8M0014002
17 37 48-8M0014031 48-8M0014032
16.75 37 48-8M0014061 48-8M0014062 Diameter (Inches) Pitch LH Rotation RH Rotation
16.5 37 48-8M0014091 48-8M0014092 18 30 48-8M0015067 48-8M0015068
16.25 37 48-8M0014121 48-8M0014122 17.75 30 48-8M0015097 48-8M0015098
16 37 48-8M0014151 48-8M0014152 17.5 30 48-8M0015127 48-8M0015128
15.75 37 48-8M0014181 48-8M0014182 17.25 30 48-8M0015157 48-8M0015158
15.5 37 48-8M0014211 48-8M0014212 17 30 48-8M0015187 48-8M0015188
15.25 37 48-8M0014241 48-8M0014242 16.75 30 48-8M0015217 48-8M0015218
15 37 48-8M0014271 48-8M0014272 16.5 30 48-8M0015247 48-8M0015248
18 38 48-8M0013913 48-8M0013914 16.25 30 48-8M0015277 48-8M0015278
17.75 38 48-8M0013943 48-8M0013944 16 30 48-8M0015307 48-8M0015308
17.5 38 48-8M0013973 48-8M0013974 15.75 30 48-8M0015337 48-8M0015338
17.25 38 48-8M0014003 48-8M0014004 15.5 30 48-8M0015367 48-8M0015368
17 38 48-8M0014033 48-8M0014034 15.25 30 48-8M0015397 48-8M0015398
16.75 38 48-8M0014063 48-8M0014064 15 30 48-8M0015427 48-8M0015428
16.5 38 48-8M0014093 48-8M0014094 18 31 48-8M0015069 48-8M0015070
16.25 38 48-8M0014123 48-8M0014124 17.75 31 48-8M0015099 48-8M0015100
16 38 48-8M0014153 48-8M0014154 17.5 31 48-8M0015129 48-8M0015130
15.75 38 48-8M0014183 48-8M0014184 17.25 31 48-8M0015159 48-8M0015160
15.5 38 48-8M0014213 48-8M0014214 17 31 48-8M0015189 48-8M0015190
15.25 38 48-8M0014243 48-8M0014244 16.75 31 48-8M0015219 48-8M0015220
15 38 48-8M0014273 48-8M0014274 16.5 31 48-8M0015249 48-8M0015250
18 39 48-8M0013915 48-8M0013916 16.25 31 48-8M0015279 48-8M0015280
17.75 39 48-8M0013945 48-8M0013946 16 31 48-8M0015309 48-8M0015310
17.5 39 48-8M0013975 48-8M0013976 15.75 31 48-8M0015339 48-8M0015340
17.25 39 48-8M0014005 48-8M0014006 15.5 31 48-8M0015369 48-8M0015370
17 39 48-8M0014035 48-8M0014036 15.25 31 48-8M0015399 48-8M0015400
16.75 39 48-8M0014065 48-8M0014066 15 31 48-8M0015429 48-8M0015430
16.5 39 48-8M0014095 48-8M0014096 18 32 48-8M0015071 48-8M0015072
16.25 39 48-8M0014125 48-8M0014126 17.75 32 48-8M0015101 48-8M0015102
16 39 48-8M0014155 48-8M0014156 17.5 32 48-8M0015131 48-8M0015132
15.75 39 48-8M0014185 48-8M0014186 17.25 32 48-8M0015161 48-8M0015162
15.5 39 48-8M0014215 48-8M0014216 17 32 48-8M0015191 48-8M0015192
15.25 39 48-8M0014245 48-8M0014246 16.75 32 48-8M0015221 48-8M0015222
15 39 48-8M0014275 48-8M0014276 16.5 32 48-8M0015251 48-8M0015252
18 40 48-8M0013917 48-8M0013918 16.25 32 48-8M0015281 48-8M0015282
17.75 40 48-8M0013947 48-8M0013948 16 32 48-8M0015311 48-8M0015312
17.5 40 48-8M0013977 48-8M0013978 15.75 32 48-8M0015341 48-8M0015342
17.25 40 48-8M0014007 48-8M0014008 15.5 32 48-8M0015371 48-8M0015372
17 40 48-8M0014037 48-8M0014038 15.25 32 48-8M0015401 48-8M0015402
16.75 40 48-8M0014067 48-8M0014068 15 32 48-8M0015431 48-8M0015432
16.5 40 48-8M0014097 48-8M0014098 18 33 48-8M0015073 48-8M0015074
16.25 40 48-8M0014127 48-8M0014128 17.75 33 48-8M0015103 48-8M0015104
16 40 48-8M0014157 48-8M0014158 17.5 33 48-8M0015133 48-8M0015134
15.75 40 48-8M0014187 48-8M0014188 17.25 33 48-8M0015163 48-8M0015164
15.5 40 48-8M0014217 48-8M0014218 17 33 48-8M0015193 48-8M0015194
15.25 40 48-8M0014247 48-8M0014248 16.75 33 48-8M0015223 48-8M0015224
15 40 48-8M0014277 48-8M0014278 16.5 33 48-8M0015253 48-8M0015254 MERCURY RACING PROPELLER CHARTS
16.25 33 48-8M0015283 48-8M0015284
16 33 48-8M0015313 48-8M0015314
15.75 33 48-8M0015343 48-8M0015344

OEM Rigging & Accessories Guide & Price List 441
