Page 497 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)
P. 497

QUICKSILVER PROPELLER TYPE



                 QA2064X                               95.19    NEMESIS
            11 1/4 X 10 RH AL 3 BL
                 QA2070X                               95.19    Introducing the Nemesis ‑ the ultimate performance aluminum propeller.
            10 7/8 X 11 RH AL 3 BL                              Do you want to take your boats performance to the next level? The
                 QA2074X                               95.19    Nemesis provides 16‑25% faster acceleration and superior holding all
            10 5/8 X 12 RH AL 3 BL                              while maintaining top speed vs. a comparable 3 blade aluminum
                 QA2072X                               95.19    propeller.
            10 3/4 X 12 RH AL 3 BL                              Hub Application:
                                                                For 25‑30 HP 4‑Stroke outoboards (Flo‑Torq I)
                 QA2078X                               95.19    40‑60 HP standard gearcase outoboards (Flo‑Torq Reflex)
            10 3/8 X 13 RH AL 3 BL                              40 Bigfoot ‑ 300 HP (Flo‑Torq II)
                 QA2076X                               95.19    The 10, 11 and 13 pitch propellers for the 40‑60 BigFoot are specifially
            10 1/2 X 13 RH AL 3 BL                              desined for excellent performance in pontoon applications.  If engine
                 QA2082X                               95.19    RPM is  appropriate with 3‑blade prop, replace with the same pitch
                                                                Nemesis propeller.
            10 1/4 X 14 RH AL 3 BL                              9.5" ‑ 19" pitch RH only
                 QA2080X                               95.19
            10 3/8 X 14 RH AL 3 BL
                 QA2084X                               95.19    NEMESIS 25-30 HP
            10 1/8 X 15 RH AL 3 BL
                                                                25‑30 HP 4‑Stroke outoboards 2006 and newer Flo‑Torq I Rubber Hub.
            BLACK DIAMOND FOR 85-140 HP EVENRUDE/               NEMESIS PROPELLER
            JOHNSON V-4

            Black Diamond Propellers designed to fit 85‑140 hp Evenrude/Johnson
            V‑4
            BLACK DIAMOND





                                                                   48-8M8027516                             90.25
                                                                9.3 X 9.5P RH Al 4 BL
                                                                   48-8M8027517                             90.25
                                                                9.3 X 11 RH AL 4 BL
                                                                NEMESIS 40-60 HP
      QUICKSILVER PROPELLER TYPE  14 X 13 RH AL 3 BL Extra Cup  25 HP BigFoot, 30 HP 4‑ Stroke (2005 and earlier) 40‑60 HP 2‑stroke
                 QA3832X
                                                       81.32
                                                                and 4‑Stroke outoboards.
            BLACK DIAMOND
                                                                Equipped with Flo‑Torq Reflex Hub system to eliminate clutch rattle.

                                                                NEMESIS PROPELLER








                 QA2208X                               94.56
            13 3/4 X 15 RH AL 3 BL
                 QA2206X                               94.56
            13.25 X 17 RH AL 3 BL                                  48-8M8027510                            112.23
                                                                10.6 X 11 RH AL 4 BL
                                                                   48-8M8027511                            112.23
                                                                10.6 X 12 RH AL 4 BL
                                                                   48-8M8027512                            112.23
                                                                10.3 X 13 RH AL 4 BL
                                                                   48-8M8027513                            112.23
                                                                10.1 X 14 RH AL 4 BL
                                                                   48-8M8027514                            112.23
                                                                10.1 X 15 RH AL 4 BL
            484                                                 Place Orders | Print Invoices | Register Product | Pay Online
   492   493   494   495   496   497   498   499   500   501   502
