Page 684 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)
P. 684
MISCELLANEOUS PARTS
MISCELLANEOUS PARTS
SCREWS SCREW
SCREW MISCELLANEOUS PARTS
10- 98794 1.60
3/8‑16 x 1 in., 12 point flange head
For mounting MCM thermostat housing, exhaust block‑off plate and Alpha/Bravo
10- 24231 .40 top cover.
#10‑24 x 1/4 in., Slotted binding head
For mounting Bravo grounding straps SCREW
Priced individually, sold @ multiples of 5
SCREW
10- 58640 2.60
3/8‑16 x 1‑1/4 in., 12 point flange head
For mounting MCM lower exhaust pipe to outer transom plate.
10- 48409 .85 Priced individually, sold @ multiples of 5
#10‑16 x 5/8 in., Stainless steel self‑tapping pan head
For mounting MCM P/T pump solenoid boot SCREW
Priced individually, sold @ multiples of 2
SCREW
10- 43749 3.05
.375‑16 x 5‑3/4 in., Hex flange head
For mounting MCM exhaust elbows
10- 78038 1.10
1/4‑20 x 1‑3/4 in., Hex head SCREW
For mounting Bravo inlet water hose connector
Priced individually, sold @ multiples of 3
SCREW
10- 53167T .45
5/16‑18 x 7/8 in., Hex head
For mounting shift cable retainer to Bravo shift bracket.
Priced individually, sold @ multiples of 16
10-864665 3.85
3/8‑16 x 7‑1/2 in., Hex head
For mounting MIE dry joint exhaust elbows.
OEM Rigging & Accessories Guide & Price List 671
