ANALOG INSTRUMENTS

ANALOG GAUGE INTERFACE MODULE ANALOG WATER PRESSURE FITTING KIT

892486T04 75.40 32-8M0063663 4.10
Replacement AGI Module: analog outputs for tach, fuel level, trim position, block Fitting kit to install analog gauge to engine.
temperature and oil pressure. F150 EFI FourStroke outboard.
For NON‑PCM09 ECUs ‑ Must have digital sensors on SmartCraft engine in order
for these to be converted to analog outputs. CDS service tool used to enable Tach
Link output (which can be either digital link data or analog trim) MONITOR PANELS FOR DIESELS
8M0109741 75.40
Replacement AGI Module: analog outputs for tach, fuel level, trim position, block PRIMARY STATION MONITOR PANEL
temperature and oil pressure.
For PCM09 ECUs ‑ Must have digital sensors on SmartCraft engine in order for
these to be converted to analog outputs. CDS service tool used to enable Tach
Link output (which can be either digital link data or analog trim)
TRIM CONVERTER AND TILT UP LIMIT KIT ANALOG INSTRUMENTS

806385T 207.53
Warning lights are provided for low oil pressure, excessive coolant
temperature, insufficient alternator output and glow plug activation.
Fits 1.7L MS & MI 120 and 4.2 MS & MI (200 & 230)
PRIMARY STATION MONITOR PANEL
8M0118725 54.06
This kit allows the conversion of the trim signal from the analog sender to a digital
output for Smartcraft gauge applications. The kit also has an additional feature that
allows the max tilt up positon to be set to avoid interference when tilting the engine
completely up.
2.1L F75‑115 Four Stroke
TRIM SENSOR CONVERTER KIT

861014 156.50
Warning lights are provided for low oil pressure, excessive coolant temperature,
insufficient alternator output, glow plug activation & check engine light.
Fits 1997 and newer 2.8 ES & EI 165 and 4.2 ES & EI (250 & 230)

8M0059529 28.55
This kit will allow you to convert the signal from the digital sensor to an analog
signal. It will allow you to drive an analog gauge for trim only without changing the
sensor to an analog sensor. This kit will connect directly to the harness inside the
emgine cowl.
F150 EFI FourStroke outboard engine only
