Page 95 - OEM RIGGING AND ACCESSORIES GUIDE (US-2017)

ANALOG INSTRUMENTS

ADMIRAL SPEEDOMETER
ADMIRAL SPEEDOMETER

79-895285Q21 18.91
Anti‑fog lens. 10‑45 MPH. 270 degree dial sweep. White face and Black 79-895285Q28 25.00
bezel; Black graduations. Includes 20 ft.(6.1 m) of tubing. Fits 3‑3/8 in. (85
mm) hole in dash. Anti‑fog lens. 10‑40 Knots. 270 degree dial sweep. White face and Black
Quicksilver Branded, Box Point of Sale Packaged. bezel; Blackgraduations. Includes 20 ft.(6.1 m) of tubing. Fits 3‑3/8 in. (85
mm) hole in dash.
Quicksilver Branded, Box Point of Sale Packaged.
ADMIRAL SPEEDOMETER ADMIRAL VOLT METER
ANALOG INSTRUMENTS

79-895285Q23 25.00
Anti‑fog lens. 10‑65 MPH. 270 degree dial sweep. White face and Black 79-895286Q21 10.05
bezel; Black graduations. Includes 20 ft.(6.1 m) of tubing. Fits 3‑3/8 in. (85
mm) hole in dash. Anti‑fog lens. White face and Black bezel; black graduations.
Quicksilver Branded, Box Point of Sale Packaged. Outboards require a tachometer harness or ignition/choke assembly for
connection.
Quicksilver Branded, Box Point of Sale Packaged.
ADMIRAL SPEEDOMETER
WATER TEMPERATURE GAUGE

79-895285Q24 25.00
Anti‑fog lens. 0‑80 MPH. 270 degree dial sweep. White face and Black 79-895287Q21 11.08
bezel; Black graduations. Includes 20 ft.(6.1 m) of tubing. Fits 3‑3/8 in. (85
mm) hole in dash. Anti‑fog lens. 100 deg.‑240 deg.F gauge. White face and Black bezel;
Quicksilver Branded, Box Point of Sale Packaged. Black graduations. Includes sender. Also requires reducer fitting 22‑86306
for 75 thru 115 FourStroke and 225 FourStroke applications. Coastal flush
units require the 12415A 2 temperature sender kit.
Fits Mercury/Mariner 25 thru 115 FourStroke, 225 FourStroke, 40 (3 & 4 cyl.), 45,
50/60 (3 cyl.), and 70 to 125 hp ; and 1993 and newer Force outboards (Force
models must order sender FA299791 and discard sender included with gauge.
Quicksilver Branded, Box Point of Sale Packaged.
