ANALOG INSTRUMENTS

ANALOG GAUGE INTERFACE - DIGITAL ENGINES ANALOG GAUGE INTERFACE (AGI) KIT

Converts digital signal to analog

DTS ENGINE - ANALOG GAUGE HARNESS ANALOG INSTRUMENTS

892486K07 126C57 210.99
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Includes AGI Module Assembly, Harness and hardware.
For installations using analog gauges instead of SmartCraft. Use with analog
tachometer, coolant temp, oil pressure or level, trim and fuel level. Enhanced
84-8M0095716 18C33 30.55 Voltage Suppression.
An analog gauge harness (15 feet) specific for DTS engines that is more cost Race MerCruiser or outboard engines in single or multiple engine installations plus
effective than the AGI (Analog Gauge Interface) solution MerCruiser 496Mag/Mag HO engines.
DTS versions of 4.5L/6.2L MerCruiser engines only Mercury Branded
84-8M0095826 21C42 35.70 ANALOG GAUGE INTERFACE (AGI) KIT
An analog gauge harness (20 feet) specific for DTS engines that is more cost
effective than the AGI (Analog Gauge Interface) solution
DTS versions of 4.5L/6.2L MerCruiser engines only
84-8M0095827 24C17 40.28
An analog gauge harness (25 feet) specific for DTS engines that is more cost
effective than the AGI (Analog Gauge Interface) solution
DTS versions of 4.5L/6.2L MerCruiser engines only
84-8M0095828 26C30 43.83
An analog gauge harness (30 feet) specific for DTS engines that is more cost
effective than the AGI (Analog Gauge Interface) solution
DTS versions of 4.5L/6.2L MerCruiser engines only
ANALOG GAUGE INTERFACE KIT 892486K04 120C97 201.66
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
For installations using analog gauges instead of SmartCraft. Use with analog
tachometer,coolant temp, oil temp, oil pressure or fuel pressure gauges. Enhanced
Voltage Suppression.
Race MerCruiser engines with the 14 pin Deutsch connector engine wiring
harness. One AGI kit per engine required.
ANALOG GAUGE INTERFACE MODULE

892486K08 95C73 159.55
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Used on 14‑pin engines to convert a digital sensor signal into analog for
Tachometer, Oil Pressure/Oil Level, Water Temperature, Trim, and Fuel Level
analog gauges. There is also a connection for SC100 Link Gauges. Enhanced
Voltage Suppression.
Used with a 10 Pin Junction Box connection, For Non‑PCM09 ECUs ‑ Fits
SmartCraft compatible 14‑pin engines
8M0109742 95C06 158.43 892486T04 85C79 142.98
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Used on 14‑pin engines to convert a digital sensor signal into analog for Replacement AGI Module: analog outputs for tach, fuel level, trim position, block
Tachometer, Oil Pressure/Oil Level, Water Temperature, Trim, and Fuel Level temperature and oil pressure.
analog gauges. There is also a connection for SC100 Link Gauges. No Voltage For NON‑PCM09 ECUs ‑ Must have digital sensors on SmartCraft engine in order
Suppression. for these to be converted to analog outputs. CDS service tool used to enable Tach
Used with a 10 Pin Junction Box connection. For PCM09 ECUs only ‑ Fits Link output (which can be either digital link data or analog trim)
SmartCraft compatible 14‑pin engines.
