P. 224
ELECTRICAL
SIDE MOUNT CONTROL HARNESS REMOTE CONTROL/ IGNITION CHOKE EXTENSION
HARNESSES
Fits Mercury / Mariner 6 hp. and Higher (2 cycle, USA & BEL Origin)
outboards, Mariner 30/40 hp. with oil injection (2 cycle, Japanese
Origin), all Mercury / Mariner 4‑Stroke (USA Origin) outboards and
Force 40 hp. and Higher (1993 and Newer). Various applications
include 7,8 and 10 pin harnesses and 12 wire (8 pin plus 4 bullet
connectors) used on side mount controls and ignition/choke assemblies.
EXTENSION HARNESS
84-8M0101080 70.62
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
15 foot side mount control non‑trim harness
Comes in 8M0083860 Side Mount Control with non‑Trim kit
ADAPTER- POWER TRIM O/B
84- 17829A 2 32.06
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
2 ft.(0.6 m) harness, 8 lead harness. ELECTRICAL
Used as harness extension or to complete two station installations.
84- 17829A10 37.45
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
84-824783A11 6.29 10 ft.(3.05 m) harness, 8 lead harness.
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov Used as harness extension or to complete two station installations.
Connects the white 3 pin trim connector (newer controls) to the old black boot 84- 17829A20 43.93
connector on the harness WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
O/B backfit adapter ‑ new control and old harness
20 ft.(6.1 m) harness, 8 lead harness.
NEUTRAL SWITCH ADAPTER - FEMALE Used as harness extension or to complete two station installations.
TWO STATION Y-HARNESSES
For boats with two station applications.
POWER TRIM "Y" HARNESS
84-8M2100450 3.54
WARNING: Cancer - www.P65Warnings.ca.gov
Female bullet to flat spade connector
Used when needed to adapt to the Neutral Switch
NEUTRAL SWITCH ADAPTER - MALE
58366T 2 27.11
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Used with Trim Control Panels and Extension Harnesses (46838__ series.
Fits MCM engines and Mercury/Mariner outboards with power trim.
84-8M2100451 3.54
WARNING: Cancer - www.P65Warnings.ca.gov
Male bullet to flat spade connector
Used when needed to adapt to the Neutral Switch
2021 OEM Rigging & Accessories Guide & Price List 211
