STEERING

HYDRAULIC HELM PUMP -Q/S-TILT HYDRAULIC STEERING ARM

8M0056144 401.80 898082A03 94.35
Front Mount 2.4 cu in (39 CC) displacement. Approximately 3 turns lock to This arm attaches the cylinder to the engine for 1.5L OptiMax engines. Remove
lock on singles (Use Compression style fittings and hoses) existing arm on 898349A01 cylinder and replace it with this arm for proper
and 6.5 on dual cylinders clearances
Compact design 1.5L OptiMax engines
Tilt Range of 48 Deg and 5 locking positions
Built‑in valve for positive rudder lock HYDRAULIC STEERING KIT -Q/S
Integral relief valve for over pressure protection
Hydraulic Steering for Verado 135 to 175‑4 stroke engines
Also can be used on OptiMax with Mercury hydraulic cylinder and hoses. Also can
be used on OptiMax with Mercury hydraulic cylinder and hoses Also can be used
on 75‑115 4 stroke and 1.5L opti 75‑115 HP
Use cylinder 8M0050097 for Std and 8M0056145 for counter for multiple engine
installs. Hose series is 8M0053474 thru 8M0053492
CYLINDER WITH COMPRESSION STYLE FITTINGS

8M0073922 739.55
Quicksilver 1.5 cu in displacement Std Helm kit with Cylinder and Hoses.
(14 ft) Approximately 5 turns lock to lock on a single engine
Hydraulic Steering ‑ 75 HP engines and above (Use with Compression
type hoses 8M0053473 thru 8M0053449)
8M0073923 762.85
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses.
8M0050097 320.29 (16 ft) Approximately 5 turns lock to lock on a single engine
Heavy Duty Hydraulic standard cylinder that uses compression hoses Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression
type hoses 8M0053473 thru 8M0053449)
8M0053474 ‑ 8M005053491. This cylinder is tested to Mercury's rigid
standards that include higher loads and cycle testing to 300,000 cycles. It 8M0073924 751.20
includes machined, high strength fasteners, electro polished SS arm, and heavy Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses.
duty triple seal cartridges for enhanced duribility and longevity (18 ft) Approximately 5 turns lock to lock on a single engine
135‑300 HP OPTI Max Outboards and 4 Cylinder Verado (Hydraulic only) Use on Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression
single, dual and triple installations type hoses 8M0053473 thru 8M0053449) 751.20
STEERING CYLINDER WITH COMPRESSION STYLE FITTINGS- Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses.
8M0073925
PORT
(20 ft) Approximately 5 turns lock to lock on a single engine
Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression
type hoses 8M0053473 thru 8M0053449)
8M0073927 762.85
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses.
(22 ft) Approximately 5 turns lock to lock on a single engine
Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression
type hoses 8M0053473 thru 8M0053449)
8M0073928 768.67
Quicksilver 1.5 cu in displacemen Std Helm kit with Cylinder and Hoses.
(24 ft) Approximately 5 turns lock to lock on a single engine
Hydraulic Steering ‑ 75 HP engines and above (Use with Comptression
8M0056145 378.52 type hoses 8M0053473 thru 8M0053449)
Heavy Duty Hydraulic cylinder counter rotation that uses compression
hoses 8M0053474 ‑ 8M005053491. This cylinder is tested to Mercury's
rigid standards that include higher loads and cycle testing to 300,000
cycles. It includes machined, high strength fasteners, electro polished SS arm, and
heavy duty triple seal cartridges for enhanced duribility and longevity
135‑300 HP OPTI Max Outboards and 4 Cylinder Verado (Hydraulic only) Use on
dual and triple installations (Counter rotation )
