Page 1072 - Quicksilver Product Guide (2020) - 8M0163242

DRIVE SYSTEMS

Model Year Range Serial # Range Bearing Carrier Cover Nut Tab Washer
Bravo I & I X - SeaCore 2007 - 2019 0W995000 and up 41641A18 8M2000347 14- 18323
Bravo I XR/XZ 2000 - 2019 0M100001 and up 840372A 2 8M2000347 14- 18323
Bravo II & II X 1988 - 2019 0B664190 and up 863913A04 54163 14- 54167
Bravo II & II X - SeaCore 2007 - 2019 0W995000 and up 863913A14 8M2000346 14- 54167
Bravo III & III X 1988 - 2019 0B664190 and up 865876A01 8M2013382 N/A
Bravo III & III X - SeaCore 2007 - 2019 0W995000 and up 865876A03 8M2013382 N/A
Blackhawk 1994 - 1995 0F186717 and up N.L.A. N.L.A. N/A
III 1968 - 1972 2373127 - 3002613 N.L.A. N.L.A. -
215H 1970 2782203 - 2909034 N.L.A. 54163 14- 54167
215E 1970 - 1972 2909035 - 2915034 N.L.A. 54163 14- 54167
TR 1973 - 1993 3377316 and up 863913A04 54163 14- 54167
TRS 1973 - 1993 3377316 and up N.L.A. 8M2000347 14- 79447
(1) casting #73020C
(2) casting #73020C1

WATER PICK UP INSERTS WATER PICK UP INSERTS

WATER PICK UP INSERTS MERCURY® MERCRUISER®

93424 1
Port side
Fits MR & Alpha One
66885
Starboard side INSERT SCREW
Fits MC‑I & R
WATER PICK UP INSERTS

10- 76156

93423 1
Starboard side
Fits MR & Alpha One
