INBOARD TRANSMISSIONS - NEW

INBOARD TRANSMISSIONS - NEW

A Quicksilver exclusive, 100% new mechanical transmission assemblies offer the best value on the market by delivering: INCLUDED rigging content
worth over $1500, mounting hardware, fluid filled and factory tested. This means everything is ready to go to install a complete inboard using a bobtail
Plus Series engine. The transmission assemblies include:
• Transmission mounting brackets, trunions and hardware
• Transmission mounts
• Heavy duty copper cooler
• Transmission fluid hoses
• Shift bracket and hardware
• Gear indicator switch
• High temperature switch
• Fresh coat of phantom black paint
The typical application is for MerCruiser, Quicksilver and Mercury Remanufacturing gasoline inboard engines. Engine couplers may need to be
changed based on the transmission and application. In general spring plate couplers are used for inline or co‑axial transmissions, and dual‑stage
couplers for V‑Drive and Downangle transmissions. If using on an existing engine, a new coupler is recommended when using a new transmission.
Also, please be sure to install and properly adjust new premium shift cables as the #1 clutch failure is from improperly adjusted shift cables that can
result in severe transmission damage. Propshaft couplers need to be sourced separately.
As a side note, ZF 63 series transmissions are in process of converting to ZF 68 series transmissions. Some SKU’s of ZF 63 series may need to
convert to ZF 68 series at the time of order. There is a price difference to consider. Quicksilver will offer the value offered by the ZF 63 series for as long
as they are available.

ZF/HURTH 45C DIRECT ACROSS ZF/HURTH 630 V-DRIVE TRANSMISSION
TRANSMISSION ASSEMBLY TRANSMISSION ASSEMBLY

8M0139548
Completely dressed. Brand new ZF 45C Coaxial inboard transmission. Includes oil 896346707
cooler, hoses, and mounting hardware. 4" output flange. Recommended for light Completely dressed, brand new V‑Drive Inboard Transmission. Includes oil cooler,
boat applications (<5000#) with engines up to 350 HP @ 5000 RPM. hoses and mounting harware.
Standard (right‑hand) Rotation
Replaces ZF 45C & Borg Warner 71C Series Direct Drive Transmission with 1.00
Gear Ratio on light boats using 5.7L, 6.2L, & 383 small block engines. Replaces ZF / Hurth HSW630V1 Transmission with 1.50:1 Gear Ratio.
896346708
ZF/HURTH 630A DOWN ANGLE TRANSMISSION Completely dressed, brand new V‑Drive Inboard Transmission. Includes oil cooler,
hoses and mounting harware.
Standard (right‑hand) Rotation
TRANSMISSION ASSEMBLY Replaces ZF / Hurth HSW630V1 Transmission with 2.00:1 Gear Ratio.
896346709
Completely dressed, brand new V‑Drive Inboard Transmission. Includes oil cooler,
896346701 hoses and mounting harware.
Completely dressed, brand new Down‑Angle Inboard Transmission. Includes oil Standard (right‑hand) Rotation
cooler, hoses and mounting harware.
Standard (right‑hand) Rotation Replaces ZF / Hurth HSW630V1 Transmission with 2.50:1 Gear Ratio.
Replaces ZF / Hurth HSW630A 1 Transmission with 1.50:1 Gear Ratio.
896346702
Completely dressed, brand new Down‑Angle Inboard Transmission. Includes oil
cooler, hoses and mounting harware.
Standard (right‑hand) Rotation
Replaces ZF / Hurth HSW630A 1 Transmission with 2.00:1 Gear Ratio.
896346703
Completely dressed, brand new Down‑Angle Inboard Transmission. Includes oil
cooler, hoses and mounting harware.
QUICKSILVER® REPOWER Completely dressed, brand new Down‑Angle Inboard Transmission. Includes oil
Standard (right‑hand) Rotation
Replaces ZF / Hurth HSW630A 1 Transmission with 2.50:1 Gear Ratio.
8M6001849
cooler, hoses and mounting harware.
Standard (right‑hand) Rotation
Replaces ZF / Hurth HSW630A 1 Transmission with 2.70:1 Gear Ratio.
