Page 397 - Quicksilver Product Guide (2020) - 8M0163242

IGNITION

MERCURY®/MARINER®/FORCE®
GASKET

27- 55896
Distributor Cap Gasket
Priced individually, sold @ multiples of 3

IGNITION CHARTS - STANDARD COMPONENTS

Standard ignition component charts are located within this section. ECM modules and their application chart will be located in a separate section of its
own.

FourStroke Ignition Chart
Model Model Notes Country Serial # Range Ignition Coil Switch Box or TPM Ass'y
2.5 FourStroke JPN 0R131842 and up - N/A
3.5 FourStroke JPN 0R131842 and up - N/A
4 FourStroke JPN 0R000001 - 0R067089 - -
BEL 0P073456 - 0P400999
4 FourStroke JPN 0R067090 and up - N/A
BEL 0P401000 and up
5 FourStroke JPN 0R000001 - 0R067089 - -
BEL 0P073456 - 0P400999
5 FourStroke JPN 0R067090 and up - N/A
BEL 0P401000 and up
6 FourStroke JPN 0R000001 - 0R067089 - -
BEL 0P073456 - 0P400999
6 FourStroke JPN 0R067090 and up - N/A
BEL 0P401000 and up
8 FourStroke Bodensee USA 0G760300 - 0T178499 N.L.A. N.L.A.
USA 0H017100 - 0H017349
8 FourStroke 323cc BEL 0P075166 - 0P325499 NLA 835401T 1
8 FourStroke 209cc USA 0R042475 and up - -
BEL 0P325500 and up
9.9 FourStroke 232cc USA 0H000058 - 0H016909 N.L.A. N.L.A.
9.9 FourStroke 323cc USA 0G760300 - 0T979999 NLA 835401T 1
BEL 0P075166 - 0P325499
9.9 FourStroke 209cc JPN 0R042475 and up - -
BEL 0P325500 and up
15 FourStroke 323cc USA 0G760300 and up NLA 835401T 1
BEL 0P075166 and up
15 FourStroke 351cc JPN 0R235949 and up - -
20 FourStroke 351cc JPN 0R235168 and up - -
25 FourStroke Carb USA 0G590000 - 1B344298 339-859738T 1 See ECMs
BEL 9973100 - 0P388282
25 FourStroke EFI JPN 0R106999 and up - See ECMs
30 FourStroke Carb USA 0G760300 - 0G960499 - See ECMs

388
