Page 498 - Quicksilver Product Guide (2020) - 8M0163242
P. 498
COOLING SYSTEM
Mercury Model Model Note Flush Kit (Non- Flush Kit (Run at WATER PUMP BASE O-RING
running) Idle Speed)
15 FourStroke 351cc 44357Q 2
20 FourStroke 351cc 44357Q 2 MERCURY®/MARINER®/FORCE®
25M/ML FourStroke Carb and EFI 44357Q 2
25EL FourStroke Carb and EFI 44357Q 2
30 Hp thru 275 Hp 44357Q 2(1)
25- 38099
MCM Sterndrives All except Bravo I Perf. & 44357Q 2(1) Priced individually, sold @ multiples of 2
Blackhawk
SCREW
(1) Gearhousings with a nose cone dual water pick-up require an additional flush seal kit 881150Q 1
to complete flush assembly.
GASKETS, SEALS & HARDWARE
INSULATOR
10- 96411
#14‑8 x 2‑1/4 in.
For mounting w/p body
WASHER
23- 43045
Priced individually, sold @ multiples of 4
IMPELLER KEY
28-8M0032833
Use with 47‑43026 series long vane impeller. 12- 20684
Fits MCM Alpha One Gen II & various O/B applications. Priced individually, sold @ multiples of 5
IMPELLER KEY WASHER
28-8M0032834 12- 38453
Use with 47‑89984 series short vane impeller. Priced individually, sold @ multiples of 3
Fits MCM I/R/MR/Alpha One & various O/B applications
Priced individually, sold @ multiples of 5
Quicksilver Product Guide 489
