Page 530 - Quicksilver Product Guide (2020) - 8M0163242

COOLING SYSTEM

Model Serial # Range Complete Upper Kit Base Assy Impeller Impeller Upper Insert Cup Face Plate
Pump Kit Repair Kit Housing
MARK 55A 1227131 and up N/A N/A N.L.A. 47- 89983T N/A - N.L.A. -
MARK 55H 983920 and up N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
MARK 58 (E), MARK 58A (M&E) 1139538 and up N/A N/A N.L.A. 47- 89983T N/A - N.L.A. - MERCURY®/MARINER®/FORCE®
MARK 75 1072997 and up N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
MARK 75A 1110600 and up N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
MARK 78 1143038 and up N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
MARK 78A 1194070 and up N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
KF3 358136 and up N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
KE4 214324 and up N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
KG4 ALL and up N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
KF5 338136 and up N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
KE7 ALL and up N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
KF7 ALL and up N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
KG7 ALL and up N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
KH7 500022 and up N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
KF9 377150 - 379008 N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
KG9 405293 - 495761 N/A N/A N.L.A. N.L.A. N/A N.L.A. N.L.A. N.L.A.
(1) Models with Aluminum upper pump housings
(2) Models with Aluminum water pumps
(3) Models with Plastic upper pump housings
(4) Models with Plastic water pumps
(5) Pump screws without insulators
(6) Pump screws with insulators
(7) Models with driveshaft retaining nut
(8) Models without a driveshaft retaining nut
(9) Models with flush hole
(10) Models without flush hole
(11) Models having plastic upper housing use a #48752 insert cup.
(12) Units already having a complete pump replacement using 46-46893A 6 should use the 2193818-2529894 serial group for components
(13) Units already having a complete pump replacement using 46-46893A 6 should use USA 3795658-4126549 grouping for components
(14) Units which have already had a complete pump replacement with the 46-46893A 6 pump should use the chart below for components

Early Mariner Impellers Model SN Code Serial # Impeller Repair Kit
Range
Model SN Code Serial # Impeller Repair Kit 8C (M) 6G1 007990 and up 47- 11590M 11656T
Range
8C (ML) 6G1 305951 and up 47- 11590M 11656T
2A 646 ALL - ALL 47- 80395M N.L.A.
8C (MUL) 6G1 700388 and up 47- 11590M 11656T
2B (M) 6A1 008801 - 47- 80395M N.L.A. 9.9C (M) 682 000551 and up 47- 84027T 46- 84277T
093604
9.9C (ML) 682 300826 and up 47- 84027T 46- 84277T
2B (M) 6A1 131232 and up 47- 80395M 814453M
9.9C (E) 682 250101 and up 47- 84027T 46- 84277T
4A (M) 6E0 001011 and up 47- 96305M N.L.A.
9.9C (EL) 682 550141 and up 47- 84027T 46- 84277T
4A (ML) 6E0 300101 and up 47- 96305M N.L.A.
15A (M) 651 00000 - 47- 95611M N.L.A.
5C (M) 6E3 102151 and up 47- 96305M NLA
000285
5C (ML) 6E3 400101 and up 47- 96305M NLA
15A (ML) 651 00000 - 47- 95611M N.L.A.
6C (M) 6H8 000317 and up 47- 11590M 11656T 300100
6C (ML) 6H8 300171 and up 47- 11590M 11656T 15C (M) 684 000101 and up 47- 84027T 46- 84277T
6D (M) 6H6 001302 and up 47- 11590M 11656T 15C (ML) 684 300101 and up 47- 84027T 46- 84277T
6D (ML) 6H6 300406 and up 47- 11590M 11656T 15C (E) 684 250101 and up 47- 84027T 46- 84277T
8A (M) 655 00000 - 47- 95611M N.L.A. 15C (EL) 684 550101 and up 47- 84027T 46- 84277T
000300
20A (M) 653 ALL - ALL 47- 95533M N.L.A.
8A (ML) 655 00000 - 47- 95611M N.L.A. 20A (ML) 653 ALL - ALL 47- 95533M N.L.A.
300100
20C (M) 6A9 000101 - 47- 84797M 97793T
8B (M) 677 000101 and up 47- 95611M 84181T
005810
8B (ML) 677 300101 and up 47- 95611M 84181T
