Page 539 - Quicksilver Product Guide (2020) - 8M0163242

POWERHEAD COMPONENTS POWERHEAD COMPONENTS

MERCURY®/MARINER®/FORCE® AIR FILTERS CRIMPING TOOL

AIR FILTER

91-803146T
Used to clamp high pressure hose clamps. Part of clamp tool kit (P/N 803146A04)
35-896247 HOSE CLAMP
Fits the L‑4 Verado outboard.
AIR FILTER

54-888441
12.8 mm diameter stainless steel stepless ear clamp.
54-850241
35-893318T02
Fits the L‑6 Verado outboard. 14.0 mm diameter stainless steel stepless ear clamp.
54-856880
HOSE CLAMP KIT 15.3 mm diameter stainless steel stepless ear clamp.
54- 13791
15.7 mm diameter stainless steel stepless ear clamp.
HOSE CLAMP KIT
54-855697
16.2 mm diameter stainless steel stepless ear clamp.
54-855228
25.6 mm diameter stainless steel stepless ear clamp.
HOSE CLAMP

91-803146A04
Various clamps and the crimping tool in a convenient plastic tray container. Kit is
originally furnished with 15 each of the 12.8mm,14.0mm, 15.3mm, 16.2mm clamps
and 5 each of the 25.6mm and 28.6mm diameter stainless steel clamps.
Aids in the installation of high pressure hose clamps.
54-888988019
22.6 mm diameter stainless steel stepless ear clamp.
Used on the new low permeation primer bulbs to provide a tight seal between the
bulb and the valve.

530
