POWERHEAD COMPONENTS

Model Country Serial # Range Center Main Brgs Crank End Brgs Main Valve Block Piston End Brgs
1400-140 CAN 7112773 and up 29- 71422 1 NLA - 29- 47270
140 Jet 0D082000 and up 31- 16756A 6 31-8M0045428 N/A 29-822553
V-135 w/Metal Caged USA 0A904646 - 0C239552 31- 67445 N.L.A. N/A 29- 67483
Main Brg. MERCURY®/MARINER®/FORCE®
V-135 w/Plastic Caged USA 0A904646 - 0C239552 N.L.A. N.L.A. N/A 29- 67483
Main Brg.
V-135 Connecting Rod USA 0C239553 - 0D082000 31- 16756A 6 N.L.A. N/A 29- 67483
#636-8118
V-135 Connecting Rod USA 0C239553 - 0D082000 31- 16756A 6 N.L.A. N/A 29-822553
#644-818141
V-135 USA 0D082000 and up 31- 16756A 6 31-8M0045428 N/A 29-822553
V-135 DFI USA 0D082000 - 0G760299 31- 16756A 6 31-8M0045428 N/A 29-822553
V-135 DFI USA 0G760300 and up 31- 16756A 6 31-8M0045428 N/A 29-822553
1500-1500XS 3502806 - 5327662 29- 71422 1 NLA - 29- 47270
1500-1500XS 8005615 - 8052649 29- 71422 1 NLA - 29- 47270
1500-1500XS 7010533 - 7112772 29- 71422 1 NLA - 29- 47270
V-150 (V-1500) USA 4868998 - 0C100860 31- 67445 N.L.A. N/A 29- 67483
V-150 USA 0C100861 - 0C239552 N.L.A. N.L.A. N/A 29- 67483
V-150 Connecting Rod USA 0C239553 - 0D081999 31- 16756A 6 N.L.A. N/A 29- 67483
#636-8118
V-150 Connecting Rod USA 0C239553 - 0D081999 31- 16756A 6 N.L.A. N/A 29-822553
#644-818141
V-150 USA 0D082000 - 1B226999 31- 16756A 6 31-8M0045428 N/A 29-822553
V-150 EFI USA 0D082000 and up 31- 16756A 6 31-8M0045428 N/A 29-822553
V-150 DFI USA 0D082000 - 0G760299 31- 16756A 6 31-8M0045428 N/A 29-822553
V-150 DFI USA 0G760300 and up 31- 16756A 6 31-8M0045428 N/A 29-822553
XR-4 USA 0B242885 - 0C239552 N.L.A. N.L.A. N/A 29- 67483
XR-4 USA 0C239553 - 0D081999 31- 16756A 6 N.L.A. N/A 29- 67483
XR-6 USA 0D082000 and up 31- 16756A 6 31-8M0045428 N/A 29-822553
V-175 (1750) USA 4301235 - 6618750 31- 67445 N.L.A. N/A 29- 67483
V-175 (1750) AUS 8058870 and up 31- 67445 N.L.A. N/A 29- 67483
V-175 USA 6618751 - 0C239552 N.L.A. N.L.A. N/A 29- 67483
V-175 USA 0C239553 - 0D081999 31- 16756A 6 N.L.A. N/A 29- 67483
V-175 USA 0D082000 and up 31- 16756A 6 31-8M0045428 N/A 29-822553
V-175 XRI USA 0D000750 - 0D081999 31- 16756A 6 N.L.A. N/A 29- 67483
V-175 EFI USA 0D082000 and up 31- 16756A 6 31-8M0045428 N/A 29-822553
V-175 DFI USA 0T178500 and up 31- 16756A 6 31-8M0045428 N/A 29-822553
V-200 (V2000) USA 4839034 - 5363917 31- 67445 N.L.A. N/A 29- 67483
V-200 USA 5363918 - 6073191 31- 67445 N.L.A. N/A 29- 67483
V-200 AUS 8061595 - 8065672 31- 67445 N.L.A. N/A 29- 67483
V-200 (2.4L) USA 6073192 - 0C291519 N.L.A. N.L.A. N/A 29- 67483
V-200 (2.5L) Connecting USA 0C291520 - 0D081999 31- 16756A 6 N.L.A. N/A 29- 67483
Rod #636-8118
V-200 (2.5L) Connecting USA 0C291520 - 0D081999 31- 16756A 6 N.L.A. N/A 29-822553
Rod #644-818141
V-200 USA 0D082000 and up 31- 16756A 6 31-8M0045428 N/A 29-822553
V-200 EFI USA 0C100861 - 0C291519 N.L.A. N.L.A. N/A 29- 67483
V-200 EFI Connecting USA 0C291520 - 0D081999 31- 16756A 6 N.L.A. N/A 29-822553
Rod #644-818141
V-200 EFI Connecting USA 0C291520 - 0D081999 31- 16756A 6 N.L.A. N/A 29- 67483
Rod #636-8118
V-200 USA 0D082000 - 1B226999 31- 16756A 6 31-8M0045428 N/A 29-822553
V-200 EFI (2.5L) USA 0D082000 and up 31- 16756A 6 31-8M0045428 N/A 29-822553
V-200 EFI (3.0L) USA 0T750164 and up 31- 88270A02 - N/A 29- 88258001
V-200 DFI USA 0G386496 - 0T325116 - - N/A 29- 88258001
V-200 DFI USA 0T325117 and up 31- 88270A02 - N/A 29- 88258001
V-220 USA 0B117316 and up N.L.A. N.L.A. N/A 29- 67483
V-225 USA 5628028 - 0D280812 N.L.A. N.L.A. N/A 29- 67483
